Single Channel 1000M Network Signal Surge Protector Lightning Arrester

Name: Single Channel 1000M Network Signal Surge Protector Lightning Arrester
Brand: ANSUN
SKU: 148618412
Availability: InStock

Negotiable MOQ: 1 Meter (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

ANSUN

Place of Origin:

China

Model Number:

AS05JH

ANSUN Lightning Technologies CO.,LTD

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name ANSUN

Place of Origin China

Model Number AS05JH

Application

1) used in over-voltage protection from lightning and EMP of network equipments, like 10/100/1000Mbps SWITCH, HUB, ROUTER, etc

2) Network computer room switch

3) Network computer room server

4) Other network interface devices

5) 24 channel integration SPD box is mainly applied in comprehensive network cabinet and switch cabinet

Features

1) 1000M transmission speed is suitable to 1000M network cable

2) Multi stage protective circuit, low residual voltage

3) Low insertion loss, quick response

4) Precise limiting voltage, high discharger current capacity

5) Micro-strip PCB design, good isolation, low interference

6) Standard 19 inch integrated 24 channels network signal SPD box

7) Stable performance, reliable work

8) Easy installation

Specification

Model	AS05JH
Max continuous operating voltage(Uc)	5VAC
Nominal discharge current(kA)	3KA
Max discharge current(kA)	5kA
Protection level(Up)	Line to line	≤15V
Line to ground	≤50V
Transmission rate	1000Mbps
Insertion loss	≤0.5 dB
Interface type	RJ45(F)
Protection form	1-8
Protection Channel	1
Dimension	682525mm
Protection Level	IP20
Installation	Series
Working conditions	Temperature:－40～＋85℃; Relative humidity:≤95％(25℃); Elevation≤3km
Note: For latest information, please contact ANSUN company
