Help Center10KA 12V DC Solar LED Light Power Supply Surge Protector
Related Products
-
40KA 500V Solar Photovoltaic DC Power Surge ProtectorNegotiableMOQ: 1 Piece -
40KA 220V DC Solar pv System Power Surge ProtectorNegotiableMOQ: 1 Piece
-
40KA 1000V Solar Photovoltaic DC Power Surge ProtectorNegotiableMOQ: 1 Piece
-
19\" Rack Power Supply PDU Lightning Protection SocketNegotiableMOQ: 1 Piece
-
380V 100KA Three Phase AC Power Surge Protector Lightning ArresterNegotiableMOQ: 1 Piece
Application
AM type DC power SPD is to prevent lightning over-voltage and transient over-voltage from damaging DC power system and equipments, which mainly used in mobile communication base, microwave communication base, telecommunication computer room, factory, airport, finance and securities
Also applied in several DC power system, such as DC distribution board, DC power supply equipment, DC distribution box, electronic information system cabinet and the output terminal of second stage power equipment
Features:
1) Temperature control circuit break technology, built-in over-current protection circuit, to completely keep away from fire disaster
2) International famous components and advanced manufacturing technique
3) Big discharger current capacity, low residual voltage
4) Remote alarm connect point(standard)
5) Clear and intuitive working condition
6) Easy installation and maintain
7) Exquisite process, can work under the hostile environment for a long time, like acid, alkali, dust, salt fog, wet, etc
Specification
Model |
AM10-12 |
Nominal operating voltage Un |
12VDC |
Max continuous operating voltage(Uc) |
18 VDC
|
Nominal discharge current(kA) |
5KA |
Max discharge current(kA) |
10kA |
Protected level |
≤150V |
Response time |
≤25ns |
flameretardantrating(UL94) |
V0 |
Protection Level |
IP20 |
Telecommand definition |
1-2: NC, 2:COM, 2-3: NO |
NC-COM: NC, COM:COM, NO-COM: NO | |
Dimension(mm) |
Single connection: 90*18*69mm double connection: 90*36*69mm |
Connecting diameter(mm2) |
line: 6 mm2above, ground line: 10 mm2above |
Working conditions |
Temperature:－40～＋85℃; Relative humidity:≤95％(25℃); Elevation≤3km |
Note: For latest information, please contact ANSUN company |
