USED CATERPILLAR TRACK BULLDOZER D10N IN VERY GOOD WORKING CONDITION

1. Dimensions

A. LENGTH W/ BLADE: 7760 mm

B. WIDTH OVER TRACKS: 3300 mm

C. HEIGHT TO TOP OF CAB: 4240 mm

D. LENGTH OF TRACK ON GROUND: 3870 mm

E. GROUND CLEARANCE: 615 mm

F. LENGTH W/O BLADE: 5590 mm

2.Undercarriage

G. TRACK GAUGE: 2550 mm

H. STANDARD SHOE SIZE: 610 mm

3. Engine

MAKE: Caterpillar

MODEL: 3412

GROSS POWER: 520 hp387.8 kw

DISPLACEMENT: 27 L

ASPIRATIONTurbocharged

4. Operational

OPERATING WEIGHT: 57410 kg

FUEL CAPACITY: 1023 L

HYDRAULIC FLUID CAPACITY: 108 L

5.Transmission

TYPE: powershift

NUMBER OF FORWARD GEARS: 3

NUMBER OF REVERSE GEARS: 3

MAX SPEED - FORWARD： 12.5 km/h

MAX SPEED - REVERSE： 15.6 km/h

6. Undercarriage

GROUND PRESSURE: 119.1 kPa

GROUND CONTACT AREA: 4.7 m2

STANDARD SHOE SIZE: 610 mm

NUMBER OF TRACK ROLLERS PER SIDE: 8

TRACK GAUGE: 2550 mm

7.Hydraulic System

RELIEF VALVE PRESSURE: 18600 kPa

PUMP FLOW CAPACITY: 408 L/min

Standard Blade

WIDTH: 4860 mm

HEIGHT: 2050 mm

CAPACITY: 17.2 m3

CUTTING DEPTH: 674 mm

Dimensions

8. PAYMENT AND SHIPMENT

In good working condition

Price: Negotiable

Locate in shanghai,China

Package: In bulk or by container

Deliver in 1-7 days after confirmation

Payment:T/T 30% deposite ,70% before loading
