36 Channels Sequential and Salvo Fire 300 M Wireless Remote Control Fireworks Firing System

Specifications

DC36R-B waterproof firing system has 36 channels in total. It is worked by 12V rechargeable internal

battery. It has the “test” function. This firing system could “salvo fire”,“sequential fire”   and “step by step

fire”.Time range is from 0.1-9.9s.

Features

1. Waterproof black case, protect the firing system very well.

2. With sequential(rapid) , salvo and step fire function. You could adjust the sequential(rapid) time by the time

table. Time range is 0.1-9.9S.

3. With low battery indicator. The LED will light when it is need to charging.

4. With LONG DISTANCE remote. Remote range is 400-500M

5. With “INPUT” and “OUTPUT” clips. Several machine could connect together.

6. Each channel with a “TEST” LED.

7.Could fire talon (consumer) igniters.

Instruction of remote

Please look the remote below:

Button“A”is for step fire-- the firing system will fire one by one when you press the “A “button.

Button“B”is for sequential fire

Button“C”is for salvo fire – all the channels will fire together

Button“D”is for return.

Notice for charge

1. You’d better cut off the power of machine when charging on AC.

2. There are two LED on the charge( red LED and green LED), both will light when charging.

3. The green LED will burn out when the electricity is full . Only the red one is light.

4. The charging time is about 8 hours. And the firing system will keep working for 5-10 hours .

Connect & Test

1. Please charge the firing system on 110V or 220V AC for 4 hours.

2. Please turn on the power switch, then move the button to “test”position. If the power lamp light and time

table shows:9.9s.It indicates the system is in good condition.

3. Please connect the products into black & red clip. After you finish it, check the button is on the “test”position. Please press the buttons of channels one by one, if the “test”LED turns RED, it means the products is in good condition. If the LED doesn’t light, you need to check the connection again.

4. Please s move the button to “fire”position, then you can fire.

Salvo fire & Sequential fire

1. Salvo: Turn on the “Rapid”button, the time table shows: 9.9s when the power was ready. After you press button”time”one time, the time table will change to 0.0s. Please press “Rapid”button , all the 20 channels will fire together.(pay attention that the you could only do the salvo fire when the A,B button on the OFF position)

2. Sequential: Turn on the “Rapid”button. Once you press the “time”button one time, the sequential time will add 0.1s. When it is adjust to the time that you need , please press “rapid” button , it will make firing system sequential fire. If you need reset sequential time, please cut off the power for about 2 seconds. (pay attention that the you could only do the salvo fire when the A,B button on the OFF position)

3. Step fire :Please make sure that the time table shows 0:0. Then move the A and B button to “on”position. You could do the step fire by press the channels one by one.

Attentions

1. It could fire the talon igniters only when using the internal 12V Li battery.

2. Please don’t make it to be short circuit for that would damage machine.

3. If connecting products in series, Because the resistively of ignition dissimilarity from different factory ,

please use the products which made by the same factory;

4. Please turn off the power switch when the circuit connecting but no need use it , and notice to do not shake machine violently;

5. Don’t press “FIRE” after pull out electrical outlet, for there is left power would ignite products;

6. Please don’t place the product in the damp , sour ,alkali and pollution environment.

Accessories & Parameters

Channels:         36

Weight:           4KG

Dimension:       35*27*12CM

Remote frequency : 433Mhz.
