2200 plate press full-auto insulating glass product line (high configuration)
- 100 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | SHARE | Place of Origin: | China | Model Number: | 2200 |
Product Description
1. insulating glass production line Performance features:
Full range computer automatic control system, capable of producing unequal insulating glass, double glazing glass, filming hollow, steel hollow glass wares
Film of automatic identification coated glass and LOW-E glass (optional)
Both cleaning machine and waterway adopt stainless steel and corrosion resistant material, durable in usage
Auto design flush dry section transport mechanism, suitable to flush 3-12 glass
Exclusively adopt multi-section frequency converter control, equipment multispeed operation optimization function, capable of realizing the motion of various glass automatically
The glass can be flushed continuously; the machine will classify the first and second glass automatically
Delivery parts of the product line adopt the shutdown buffering function to avoid the impact between the glass and the equipment localization, as well as reduce the abrasion of the glass to the feed wheel effectively.
2.insulating glass production line Technical parameters
Power supply | 380v 50hz |
Total power | 27kw |
Working air pressure | 0.5mpa-0.8mpa |
Flush speed | 3m-12m/min |
Transfer speed | 45m/min |
Min. glass dimension to be flushed | 450mm*400mm |
Max. glass dimension to be flushed | 2200mm*2600mm |
Thickness of insulating glass | 40mm |
Glass thickness | 3mm-12mm |
External dimension | 20800mm*26oomm*3350mm |
Weight (Approx.) | 4000kg |
