Help CenterStator Winding Machine
Negotiable
MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
NIDE
Place of Origin:
China
Model Number:
ND-TS-1A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Commutator Hotstacking MachineNegotiableMOQ: 1 Kilogram -
Automatic Positioning Armature Dynamic Balancing MachineNegotiableMOQ: 1 Kilogram
-
Automatic Armature Insulation Paper Inserting MachineNegotiableMOQ: 1 Kilogram
-
Automatic Electric Motor Rotor Production LineNegotiableMOQ: 1 Kilogram
-
Commutator Turning MachineNegotiableMOQ: 1 Kilogram
Brand Name
NIDE
Place of Origin
China
Model Number
ND-TS-1A
This type of stator winding machine is suitable for two-poles stator winding. It's self-locked, quick and convenient.
Main electrical configuration:
1.Mitsubishi PLC
Function and characteristic:
1.Manually fitting mould,and straining and releasing the mould with hand control lever.
2.Automatically winding
3.Quickly replace the tooling gripper;
4.Travel,tilt angle can be adjusted;
5. It is easy to set parameters, alarm available.
Main technical parameter:
1.Wire range:0.15—1.3mm
2.Stack length: 20—60mm
3.Pole: 2
4.Turns range: 0—99999
5.Stator O.D: 50—150mm
6.Main spindle speed:0—450RPM
7.Air pressure:5-7kg/cm2
8.Voltage:415v/3, 50/60HZ
9.Motor power: 4.5KW
10.Weight: 1.2T
11.Dimension: 1050*2300*1750mmMain electrical configuration:
1.Mitsubishi PLC
2.EV4300C GOT
3.Mitsubishi frequency converter
4.Airtec cylinder and air source part
5.Mitsubishi tension control unit or Wanner(at your option)
