Vertical Straight Line Edging Machine With 45'
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Yuanda
Place of Origin:
China
Model Number:
YD-EM-10-45\'
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Vertical Straight Edging Machine With 45\'NegotiableMOQ: 1 Piece -
Vertical Straight Edging Machine With 45\'NegotiableMOQ: 1 Piece
-
Vertical Straight Line Edging Machine With 45\'NegotiableMOQ: 1 Piece
-
Vertical Straight Line Edging Machine With 45\'NegotiableMOQ: 1 Piece
-
Horizontal Flat Tempering FurnaceNegotiableMOQ: 1 Piece
Brand Name
Yuanda
Place of Origin
China
Model Number
YD-EM-10-45\'
Detailed Product Description
Edging slant angle changing 0 and 45 degree
4 wheels for slant
No need change wheels
Glass edging machine
The 10 spindles mitering machines give perfect arri, flat bottom edge and angle various slant at one pass.
Machine Character
- Single chip controller
- Frequency speed adjust
- Electric thickness, angle adjustment adjustment
- High speed inducing motor. Speed 2480rppm/min.
- Conveyer chain
- Stainless steel water tank
- Cast steel machine base
- Pneumatic polishing assistant, polishing with felt wheel and cerium oxide for slant
- Aluminum or steel glass support for option
Machine specification
- Max.glass size: 3000x3000mm
- Min.glass size:80x80mm
- Glass thickness range: 3~26mm
- Angle change range: 0 and 45 degree
- Overall dimension (L.W.H):7500x1000x2600mm
- Worktable height: 750mm
- Weight: 33000kg
- Installed power: 22kw
- Working speed: 0.7-5.0m/min
