New Wheel Loader With 3.0T Capacity
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Guohua
Place of Origin:
China
Model Number:
ZL30F
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
ZL30FS Compact Tractor LoaderNegotiableMOQ: 1 Piece -
5.0T Rough Terrain Forklift ZL50FNegotiableMOQ: 1 Piece
-
ZL06F Small Tractor Front End LoaderNegotiableMOQ: 1 Piece
-
Mini Wheel Loader New Model ZL08F With Log GrabNegotiableMOQ: 1 Piece
-
EPA Approval 1T Wheel Loader ZL10FNegotiableMOQ: 1 Piece
Brand Name
Guohua
Place of Origin
China
Model Number
ZL30F
1. Diesel engine: that is high power and torque, low fuel consumption, low noise, and high reliability. Air filter is standard equipment for dusty fields.
2. Hydraulic torque-converter: hydraulic transmission and operation can make full use of engine power. Fully hydraulic steering, power shift transmission, hydraulic control device work with two lightweight flexible operations making the action smooth and reliable.
3. Twin pump-merging flow of working pump and steering pump: that make more engine power is available to breakout and lift forces.
4. Pilot control system: that makes operation easy and comfortable.
5. Hydraulic quick hitch/coupler: that makes it easier and quicker to change the bucket into any of the optional accessories (such as log grab, snow blade, pallet fork, sugar cane grab, hay grab, bale grab, drum grab, timber grab, street sweeper, etc.), one machine can be used as many as 10+ machines.
6. Four-wheel-drive: that makes the machine have very good off-road performance and traction.
7. Brake system: Air over hydraulic disc brake on 4 wheels system and expire brake is used in brake system, which has large brake force and makes stable brake and high safety.
8. Articulated frame: Central articulated frame, small turning radius, mobile and flexible, lateral stability, easy to operate in the narrow space.
9. Big loading engine side covers: that are made in steel are of good appearance and suitable for maintenance.
10. Comfortable cabin: that could have a broad view, easy-to-read gauges display and ergonomically designed controls make the driving convenient and comfortable.
|
Model: ZL30F
|
||
|
|
Item
|
Parameters
|
|
Performance
|
1. Rated Load
|
3000kg
|
|
2. Total Weight
|
9600kg
|
|
|
3. Rated Bucket Capacity
|
1.7-2.5m3
|
|
|
4. Max. Ttractive Force
|
≥97KN
|
|
|
5. Max. Breakout Force
|
≥127KN
|
|
|
6. Max. Gradeability
|
30°
|
|
|
7. Max. Dumping Height
|
3100mm
|
|
|
8. Max. Dumping Reach
|
1006mm
|
|
|
9. Overall Dimension (L x W x H)
|
6890*2430*3070mm
|
|
|
10. Min. Turning Radius
|
5097mm
|
|
|
Engine
|
11. Model
|
YUCHAI YC6B125-T20/CUMMINS 6BT5.9-G2
|
|
12. Type
|
Vertical, In-line, Water Cooling, 4-stroke Diesel Engine
|
|
|
13. No. of Cylinder-Bore/Stroke
|
6-108×125mm
|
|
|
14. Rated Power
|
92kw
|
|
|
15. Max. Torque
|
500N·m
|
|
|
16. Min. Fuel-consume Ratio
|
≤210g/kw·h
|
|
|
Transmission System
|
17. Torque Converter
|
YJ315-X
|
|
18. Gearbox Mode
|
Countershaft Power Shift
|
|
|
19. Gear Shift
|
4 Forward Shift, 2 Reverse Shift
|
|
|
20. Max. Speed
|
40km/h
|
|
|
Drive Axle
|
21. Main Reducing Mode
|
Bevel Gear Grade 1 Reduction
|
|
22. Hub Reduction Mode
|
Planetary Reduction Grade 1
|
|
|
23. Wheel Tread
|
1800mm
|
|
|
24. Wheel Base
|
2660mm
|
|
|
25. Min. Ground Clearance
|
400mm
|
|
|
Hydraulic System
|
26. System Working Pressure
|
16.5MPa
|
|
27. Boom Raising Time
|
4.8s ± 0.2s
|
|
|
28. Total Cycle Time
|
9.15s ± 0.5s
|
|
|
29. Fuel Tank Capacity
|
156L
|
|
|
30. Automatic Release Function
|
Yes
|
|
|
Brake system
|
31. Service Brake
|
|
|
32. Parking Brake
|
Manual Disc Brake
|
|
|
Tyre
|
33. Type Specification
|
17.5-25-20PR
|
|
34. Front Tyre Pressure
|
0.4Mpa
|
|
|
35. Rear Tyre Pressure
|
0.18Mpa
|
