Sftp Cat6 Lan Cable

Name: Sftp Cat6 Lan Cable
Brand: lasun,CCB
SKU: 148026826
Availability: InStock

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

lasun,CCB

Place of Origin:

China

Model Number:

Shenzhen CCB Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name lasun,CCB

Place of Origin China

Shielded twisted pair cable (STP), category 6 (300 MHz), 4 pairs, stranded (patch), 26AWG

Specifications:
Meets ANSI/EIA/TIA 568-B.2-1 requirements Fire protection – CM The cable meets UL 1581 VW-1 fire safety standard

Description:
Shielded Copper cable, 4 pairs, category 6, stranded (patch) 4 separately foil-shielded pairs Cable is used for indoor installation

Materials:
Conductive material: wire made of soft annealed electrolytic copper Conductor insulation: HDPE, film-porous-film structure The cable jacket: PVC Shield: every pair is separately shielded with polyester aluminum foil, which covers 100% of twisted pair

Technical characteristics:
Conductor diameter: 7 x 0.16 mm (7 x 0.006") (26 AWG) Insulated conductor diameter: 0.98 mm (0.038") Outer cable diameter: 5.9 mm (0.23") Jacket thickness: 0.4 mm (0.015") Minimum bend radius: 8 outer cable diameters Conductor elongation: 14% minimum Operating temperature: -5°C – +60°C (+23°F – +140°F) Weight per 1000 ft (304.8 m): 12.2 kg (26.9 lbs) Standard package: 500 m (1640 ft)

Electrical characteristics:
Frequency, MHz	Pair attenuation, dB/100m (dB/100ft)	NEXT losses, dB	RL, dB
1	2.8 (0.85)	85	20
4	5.4 (1.6)	85	23
10	8.6 (2.62)	85	26
16	10.7 (3.26)	85	26
31.25	14.8 (4.51)	85	24
62.5	21.5 (6.55)	80	22
100	28 (8.53)	80	20
200	40.5 (12.3)	80	17.5
300	50.5 (15.39)	75	16

Maximum conductor resistance at 20°C (68°F)	145 Ohm/km (233.35 Ohm/mile)
Resistance unbalance	2% max.
Resistance at the frequency of 1-600 MHz	100 ± 15 Ohm
Transfer impedance at the frequency of 1-10 MHz	10 MOhm/m (3.05 MOhm/ft) max.
Insulation resistance at 20°C (68°F)	5 GOhm/km (8.05 GOhm/mile) min.
Capacitive unbalance at 1 kHz relative to earth	1.5 pF/m (0.46 pF/ft) max.
Maximal voltage	30 V RMS
Dielectric power	700 V/1min
Propagation velocity	79-80%
Max. derivation of propagation delay at the frequency of 1 MHz	5.7 ns/m (1.74 ns/ft)
Max. derivation of propagation delay at the frequency of 10 MHz	5.4 ns/m (1.64 ns/ft)
Max. derivation of propagation delay at the frequency of 100 MHz	5.3 ns/m (1.61 ns/m)
Max. derivation of propagation delay at the frequency of 1-600 MHz	30 ns/100 m (9.14 ns/100 ft)
