Twisted Pair Cable (UTP), 4 Pairs, Category 6, Solid, LSZH

Name: Twisted Pair Cable (UTP), 4 Pairs, Category 6, Solid, LSZH
Brand: lasun,CCB
SKU: 148025926
Availability: InStock

US$ 0.1 - 0.9 MOQ: 1000 Pieces

Key Specifications

Brand Name:

lasun,CCB

Place of Origin:

China

Model Number:

cat6

Shenzhen CCB Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name lasun,CCB

Place of Origin China

Model Number cat6

Description:
Unshielded Copper cable, 4 pairs, category 6, solid Application: horizontal wiring in LAN Cable is used for indoor installation Meets UL444/UL1581 fire safety standard and TIA/EIA 568A

Technical characteristics:
Conductor: annealed bare copper 0.55+-0.01 mm, 23-24 AWG Insulation: HDPE, minimum average thickness 0.22 mm, minimum thickness at any point 0.21 mm Insulated conductor diameter: 0.96+-0.01 mm Identification: - Blue-White/Blue, - Orange-White/Orange, - Green-White/Green, - Brown-White/Brown 4 twisted pairs with spacer (PE) Jacket: LSZH, minimum average thickness 0.45 mm, minimum thickness at any point 0.4 mm Outer cable diameter: 6.2+-0.2 mm Minimum bend radius: 8xO while installation, 6xO while vertical cabling, 4xO while horizontal cabling Standard package: 21.5x42x42 cm (WxHxD) - 305 m Weight of cable without package: 12.9 kg Weight of cable with package: 13.8 kg Weight per 1 km: 42.3 kg Rating temp: 75°C Flame test: CM Standard: UL444/UL1581, TIA/EIA 568B.2

Electrical characteristics:
Frequency, MHz	RL	Attenuation, dB	NEXT, dB	PSNEXT, dB	ELFEXT, dB	PSELFEXT, dB
1.0	20.0	2.4	74.3	72.3	67.8	64.8
4.0	23.0	3.8	65.3	63.3	55.8	52.8
8.0	24.5	5.3	60.8	58.8	49.7	46.7
10.0	25.0	6.0	59.3	57.3	47.8	44.8
16.0	25.0	7.6	56.3	54.3	43.7	40.7
20.0	25.0	8.5	54.8	52.8	41.8	38.8
25.0	24.3	9.5	53.3	51.3	39.8	36.8
31.25	23.6	10.7	51.9	49.9	37.9	34.9
62.5	21.5	15.4	47.4	45.4	31.9	28.9
100.0	20.1	19.8	44.3	42.3	27.8	24.8
200.0	18.0	29.0	39.8	37.8	21.8	18.8
250.0	17.3	32.8	38.3	36.3	19.8	16.8

Conductor resistance at 20°C (68°F)	9.38 Ohm/100 m (2.9 Ohm/100 ft)
DC Resistance Unbalance	5%
Pair-to-Ground Capacitance Unbalance	330 pF/100 m (101 pF/100 ft)
Impedance 0.772-100 MHz	85-115 Ohm
Mutual Capacitance	5.6 nF/m (1.7 nF/ft)
Spark Test	2.5 kV
