PLC Splitter Bare Fiber

Parameters

1×2

2×2

1×4

2×4

1×8

2×8

1×16

2×16

1×32

2×32

1×64

Operating Wavelength(nm)

1260~1650

Insertion Loss (dB)(P/S Grade)

3.8/4.0

4.0/4.2

7.1/7.3

7.6/7.6

10.2/10.5

11.0/11.2

13.5/13.7

14.4/14.6

16.5/16.9

17.5/17.9

20.5/21.0

Loss Uniformity (dB)

0.4

0.6

0.6

1.0

0.8

1.2

1.2

1.5

1.5

2.0

2.0

Return Loss (dB)(P/S Grade)

55/50

Polarization Dependent Loss(dB)

0.2

0.2

0.2

0.2

0.2

0.3

0.25

0.3

0.3

0.4

0.35

Directivity(dB)

55

Wavelength Dependent Loss(dB)

0.3

0.3

0.3

0.4

0.3

0.5

0.5

0.5

0.5

0.5

0.5

Temperature Stability(-40~85°C)(dB)

0.4

0.4

0.4

0.4

0.4

0.4

0.5

0.5

0.5

0.5

0.5

Operating Temperature(°C)

-40~85

Storage Temperature(°C)

-40~85

Optical fiber length (m)

1m or customer specified

Fiber Type

ITU G652.D / G657.A or customer specified
