The pottery ball mill is the key equipment for grinding after the crushing process, and it is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics, it also can be used for the dry and wet grinding for all kinds of ores and other grindable materials.
Advantages:
1. Wet and dry intermittently to mill, mix, and discharge material
2. Large processing volume
3. It is mainly used for ceramic raw material grinding, such as feldspar, quartz, clay, etc.
4. The slurry can pass through 1000 sieve pore
5. It is a super fine grinding mill, so the material should be medium size or below to get the best grinding efficiency
Structure:
The pottery ball mill is composed of feeding part, discharging part, turning part and driving part (reducer, small driving grear, electric motor and electric control.) The quill shaft adopts cast steel part and the liner is detachable. The turning gearwheel adopts casting hobbling process and the drum is equipped with wear-resistant liner, which has good wear-resistance. The machine is with stable and reliable working condition. Moreover, according to different materials and discharging methods, there are dry ball mills and wet ball mills for choice.
The pottery ball mill is horizontal cylindrical rotation device, driven by brim gearwheel. There are two chambers and grid. Material goes into the first chamber through the feeding inlet. Inside the first chamber, there are stage liners and ripple liners as ell as steel balls. The shell rotates so as to generate electricity, and this force brings ball to a certain height and then balls drop down by gravity, the impact is the grinding force to the material. After the primary grinding, materials go into the second chamber through segregate screen. In the second chamber, there are flat liners and steel ball. After the secondary grinding, material is discharged from the discharging mouth. Then the whole grinding process is ended.
Detail Technical Parameters of Our Pottery Ball Mill are in our Website
Technical Specifications:
|
Model |
TCQ910×1120 |
TCQ1200×1400 |
TCQ1500×1800 |
TCQ1800×2100 |
TCQ2100×2100 |
TCQ2200×2400 |
TCQ2500×2900 |
TCQ2800×3700 |
TCQ3000×3700 |
|
Capacity(t/batch) |
0.2 |
0.5 |
1 |
1.5 |
2.5 |
3 |
5 |
8 |
10 |
|
Cylinder speed(r/min) |
36 |
32 |
28 |
26 |
22 |
20 |
16 |
14.5 |
14 |
|
Motor power(KW) |
5.5-11 |
11-18.5 |
15-22 |
18.5-30 |
22-37 |
28-45 |
37-55 |
55-75 |
75-90 |
|
Weight(t) |
2.6 |
4.3 |
6.5 |
8.8 |
13 |
15 |
19 |
26 |
32 |
