. Camera X-axis linear bearing 2 Lubricate them from the grease nipples . (at four locations).
1D3C-X039EA .
(Seen from the arrow shown above.)
3
1D3C-464E
1D3C-463E
1D3C-509E
4
1D3C-510E

SERVO
OFF ( ) ON (
)
5. Turn ON the servo switch.
1E3C-E-MMB01-A03-01
1.7 Every-1500-Hour Check (Once per Three Months)
1.7.2 Cleaning and Lubricating the XY Table (X- and Y-Axis Linear Bearings)
Tools Allen wrench Time required 15 to 20 minutes
1. Turn OFF the power and stop the air supply.
. Lock the power supply switch and the main air valve.

1D3C-040E
2
Open the front, rear, center safety cover, and the rear cover.
3
Pull out the cleaning unit.
Name
c
Cleaning unit
d
Center safety cover

21
1D3C-418P
4. Remove the cover.
1 . Unbolt the four hexagon head bolts, and remove the cover . by sliding it to the front side.
1D3C-435E
To the next page
Page 1-66 1E3C-E-MMB01-A03-01 1
2
1D3C-440E
1.7 Every-1500-Hour Check (Once per Three Months)

5. Clean the linear bearings, and lubricate them.
.
X-axis linear bearing Lubricate them from the grease nipples.
.
Y-axis linear bearing Lubricate them from the grease nipples.
6
After lubrication is complete, attach the cover that was removed at step 4.
7
Return the cleaning unit into the main body.
8

Close the front, rear, center safety cover, and the rear cover.
1E3C-E-MMB01-A03-01
1.7 Every-1500-Hour Check (Once per Three Months)
1.7.3 Cleaning and Lubricating the Squeegee-Axis Linear Bearings
Tools Time required 5 to 10 minutes
1. Turn OFF the power and stop the air supply.
. Lock the power supply switch and the main air valve.
1D3C-040E  2. Open the front and the rear safety cover.
2  3. Clean the linear bearings, and lubricate them. . Squeegee-axis linear bearing Lubricate them from the grease nipples.
Name dRecognition unit and squeegee head linear way

1D3C-507E
1
Page 1-68 1E3C-E-MMB01-A03-01 1.7 Every-1500-Hour Check (Once per Three Months)
1.7.4 Cleaning and Lubricating the Mask-Cleaning Y-Axis Linear Bearings
This unit sucks the solder clogging in the mask apertures and cleans the back of mask.
Tools Time required 3 to 4 minutes
1. Turn OFF the power and stop the air supply.
. Lock the power supply switch and the main air valve.
2. Open the front and the center safety
1D3C-040E

cover.
3. Clean the linear bearings, and lubricate them.
.
1D3C-AL
1
1E3C-E-MMB01-A03-01
1.7 Every-1500-Hour Check (Once per Three Months)
1.7.5 Cleaning and Lubricating the Print Inspection Head and the Recognition Head (Stopper-Coupling-Section Linear Guide)
Tools Time required 3 to 4 minutes
1. Turn OFF the power and stop the air supply.

. Lock the power supply switch and the main air valve.
1D3C-040E
2
Open the front and the rear safety cover.
3
Clean the linear guide, and apply grease
to it. . For SP80V (Print inspection head)
.
1
1D3C-X039BK
