| 1. Press | ||||||
| in the main menu. | ||||||
| . The <Machine adjustment menu> screen is displayed. | ||||||
| UNLOCK | ||||||
| 2. Press | ||||||
| + [Squeegee open/close]. | ||||||
| . The <Squeegee open/close> screen is displayed. | ||||||
| . This step uses the screen of SP80V for description. | ||||||
| UNLOCK | ||||||
| 3. Press | ||||||
| + [Squeegee open (Squeegee exchange)]. | ||||||
| . The squeegees open. | ||||||
| To the next page | ||||||
| Page 1-26 | ||||||
| 1E3C-E-MMB01-A02-00 | ||||||
| 1.3 Every-24-Hour Check (Daily) | ||||||
| SERVO OFF ( ) ON ( ) | ||||||
| 1 | ||||||
| 2 | ||||||
| 3 | ||||||
| 1D3C-X039HA | ||||||
| 1D3C-150VC0 | ||||||
| 4 | ||||||
| Turn OFF the servo switch. | ||||||
| 5 | ||||||
| Open the front safety cover. | ||||||
| 6 | ||||||
| Remove the squeegees from the squeegee head. | ||||||
| . Loosen the screws. | ||||||
| Name | ||||||
| c | ||||||
| Squeegee head | ||||||
| d | ||||||
| Screw | ||||||
| e | ||||||
| Squeegee | ||||||
| 7. Clean the squeegees. | ||||||
| . Scrape away the solder adhering to the squeegees using the squeegee cleaning jig or a plastic spatula, then wipe off the remaining solder using IPA or ethanol. | ||||||
| 1 | ||||||
| 1E4C-410P | ||||||
| Name | ||||||
| cSqueegee cleaning jig | ||||||
| 8 | ||||||
| Set squeegees. | ||||||
| 9 | ||||||
| Close the front safety cover. | ||||||
| To the next page | ||||||
| 1E3C-E-MMB01-A02-00 Page 1-27 1.3 Every-24-Hour Check (Daily) | ||||||
| SERVO | ||||||
| 10. Turn ON the servo switch. | ||||||
| ) ON ( | ||||||
| ) | ||||||
| OFF ( | ||||||
| UNLOCK | ||||||
| 11. Press | ||||||
| + [SQ. close]. | ||||||
| . The squeegee head closes. | ||||||
| . After the completion, pressing | ||||||
| returns | ||||||
| the screen to the <Machine adjustment | ||||||
| menu> screen. | ||||||
| Page 1-28 1E3C-E-MMB01-A02-00 1.3 Every-24-Hour Check (Daily) | ||||||
| 1.3.4 Cleaning the Board-Positioning Lift (After Operation) | ||||||
| After operation, clean the support plate, clamping claws, and recognition hole of board-positioning unit. | ||||||
| Tools Recognition-hole cleaning jig Time required 3 to 4 minutes | ||||||
| NOTICE | ||||||
| This maintenance is carried out with the power supply switch ON. In performing a | ||||||
| work inside the moving part, be sure to open the safety cover. | ||||||
| (Opening the cover interrupts the power supply to the moving-part motor.) | ||||||
| 32 | ||||||
| 1D3C-453E | ||||||
| Name 1 | ||||||
| c | ||||||
| Support plate | ||||||
| d | ||||||
| Clamping claw | ||||||
| e | ||||||
| Recognition hole of board-positioning unit | ||||||
| 1D3C-181CC0 | ||||||
| 1. Press in the main menu. | ||||||
| . The <Machine adjustment menu> screen is displayed. | ||||||
| UNLOCK | ||||||
| 2. Press | ||||||
| + [Transport oper]. | ||||||
| . The <PCB transfer> screen is displayed. | ||||||
| . This step uses the screen of SP80V for description. | ||||||
| To the next page | ||||||
| 1E3C-E-MMB01-A02-00 Page 1-29 1.3 Every-24-Hour Check (Daily) | ||||||
| SERVO | ||||||
| ) ON ( | ||||||
| ) | ||||||
| OFF ( | ||||||
| 1D3C-417P | ||||||
| SERVO | ||||||
| ) ON ( | ||||||
| ) | ||||||
| OFF ( | ||||||
| 4 | ||||||
| Turn OFF the servo switch. | ||||||
| 5 | ||||||
| Open the front safety cover. | ||||||
| 6 | ||||||
| Clean the clamping claws, support plate, and recognition hole of board-positioning unit. | ||||||
| . | ||||||
| Wipe off adherents using cloths dampened with IPA or ethanol. |
