Bottle Filler, Intelligent Piston Automated Filling Machine For High Viscous Liquid
Description:
1. Specialized for high viscous liquid
2. Piston filling
3. In many industries
4. Accurate measurement: Adopt servo systems to control to ensure filling accuracy.
5. Variable-speed filling: During the filling process, when filling capacity approach to the target filling volume, can adopt Variable speed to realize slow speed filling, to prevent the liquid spill the jug to avoid pollution.
6. Convenient adjustment: It only needs to revise parameters in touch screen to change filling capacity specifications. All the filling heads change in place at once. In addition, slight adjustment of material dosage can be completed in touch screen.
Applications:
Applicable materials: Cream-type, suspending agent, seed coatings, High viscosity materials and other high viscosity materials.
Applicable industries: Food, pharmaceuticals, daily chemical, pesticide and other industries.
Specifications:
|
Filling head |
16heads (6/8/10/12/16 heads can be selected) |
|
Suitable bottle diameter |
Φ40-100mm |
|
Bottle height |
82-230mm |
|
Measure precision |
±1%(within 200ml),±0.5%(200-1000ml) |
|
Volume |
80～1000ml |
|
Production capacity |
≤6000bottle / hour |
|
Air pressure |
0.6-0.8MPa |
|
Amount of Air-consuming |
200L/minute |
|
Power supply |
220V,50Hz or others |
|
Total Power |
2.5KW |
|
Weight |
1300KG |
|
Overall Dimension |
2400×1200×2300(L×W×H)mm |
|
Fob Shanghai |
USD23500/SET (16heads) |
Competitive Advantage:
Technical performance:
The filling process is under control of PLC. All operation complete on the touching screen. It adopts the piston filling way. It suits for liquid .filling within chemical, daily chemical, food, cosmetic, medicine and pesticide etc, especially fitting for high-viscous materials filling.
It has simple structure, convenient operation. It is fairly ideal and economic filling equipment for high-viscous material filling.
