Mimaki Cutting Plotter
Negotiable
/ Kilogram
1 Kilogram(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Mimaki | Place of Origin | China | |
| Model Number | CG-60SR |
Product Description
| CG-60SR | ||
|---|---|---|
| Acceptable sheet width |
90-740mm (roll sheet:90-640mm), 3.6" - 29.1" (3.6"- 25.2")
|
|
| Effective cut area*1 |
Normal : 586mm x 51m (23.1" - 167') Expand : 606mm x 51m (23.8" - 167') |
|
| Maximum speed | 85cm/s (33.4"/s) pen-up speed at 45° | |
| Adjustable speed range |
1-10cm/s: 1cm step (0.39"-3.94"/s: 0.39" step) 10-60cm/s: 5cm step (3.94"-2.36"/s: 2.0" step) |
|
| Repeatability | ±0.2mm (excluding shrinkage/expansion caused by the film temperature) | |
| Guaranteed cutting range |
586mm x 2m (23.0" - 78.7")
|
|
| Maximum cutting force |
400g
|
|
| Range of down pressure | Cutter | 10~20g(2g step), 20~100g(5g step), 100~400g(10g step) |
| Pen | 10~20g(2g step), 20~100g(5g step),100~150g(10g step) | |
| Acceptable sheet width |
Marking film up to 0.25mm (0.001") thickness: Vinyl, Fluorescent type vinyl, Reflective sheet *2 |
|
| Applicable tools*3 | Cutter, Water based ball-point pen, Oil based ball-point pen | |
| Command | MGL-IIc | |
| Interface | USB | |
| Receiver buffer size | 30 MB (20MB when in sorting) | |
| Operational conditions | 5~35°C(41~95°F), 35~75%Rh, No-condensation | |
| Power requirement | AC100V~240V Less than 100VA | |
| Dimensions (WxDxH) | 960 x 430 x 335mm (37.8" x 16.9" x 13.2") | |
| Weight | 18kg (39.7lbs.) |
