Mimaki Cg-130srii Paper Cutting Plotter

Name: Mimaki Cg-130srii Paper Cutting Plotter
Brand: MImaki
SKU: 147819194
Availability: InStock

US$ 1 - 1 MOQ: 1 Kilogram

Key Specifications

Brand Name:

MImaki

Place of Origin:

China

Model Number:

cg-130srii

Shanghai Signking Trading Company

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name MImaki

Place of Origin China

Model Number cg-130srii

	CG-100SRII	CG-130SRII
Acceptable sheet width	90-1,250mm (3.54"-49.2")	90-1,550mm (3.54"-61.0")
Effective cutting area *1	1,070mm (42.1")	1,370mm (53.9")
Maximum cutting speed	85 cm/s (33.5"/s) (at the angle of 45)
Adjustable speed range *2	1-10cm/s:1cm step adjustment (0.39"-3.94" /s:0.39" step adjustment)
10-60cm/s 5cm step adjustment (3.94"-23.6" step adjustment)
Repeatability	0.2mm / 2m (Excluding shrinkage / expansion caused by film temperature)
Effective Repeatabilit	1,050mm x 2m	1,350mm x 2m
Pen pressure	400g
Range of down pressure	Cutter	10-20g (2g step), 20-100g (5g step), 100-400g (10g step)
Pen	10-20g (2g step), 20-100g (5g step), 100-150g (10g step)
Acceptable sheet *3	Vinyl up to 0.25mm (0.01") thickness, Fluorescent type vinyl, Reflective sheet
Applicable tools *4	Cutter, Water based ball-point pen, Oil based ball-point pen, Pouncing tool
Type of command	MGL-IIc / Ic1
Interface	USB,RS-232C
Receiver buffer size	30MB Standard
Operational environment	5-35°C (41-95 °F), 35-75 %(Rh) Non-condensation
Power requirement	AC100 V-240V, 120VA or less
Dimensions (WxDxH)	1,435mm (56.5")x580mm (22.8")x1,125mm (44.3")	1,735mm (68.3")x580mm (22.8")x1,125mm (44.3")
Weight (with stands)	38kg (83.8lbs)	44kg (97.0lbs)
