- Introduction
The ANYA series intelligent high protection meter box uses the new type environmental protection material Pc on the case. It features high insulation, good transparent color, anti-UV performance, aging resistance, acid rain resistance, salt mist resistance, low & high temperature resistance, shock resistance, and have good ventilation, good heat radiation, rain-proof as well. The normal life of this device is no less than 20 years.
This series meter box adopt integrated design concept, collect the different electric meters into the sealed meter box. Which make it not only save space, but also make it easy to install and manage, perform the anti-theft action as well.
This series meter boxes with good appearance, line fluency, through the reserved screw hole on the rear of case, it can be easily installed on the concrete wall stably.
The window is transparent so that electricity consumption value can be read without opening the box, which removes the hidden trouble and realize the target: safety first, precaution crucial.
- Technical Data
Rated main busbar circuit(In): 10A~225A.
Rated main busbar short time withstand current(Icw): 30kA
Insulation resistance :≥20M
Rated insulation voltage(Ui): 220V-690V
Frequency: 50Hz/60Hz.
Safety protection grade: IP43
Main configuration please refer to the following contents.
Installation and usage:
Please make sure the device in good condition.
Please make sure the device is installed vertically and angle of Inclination should not exceed5℃.
The installation place is free from shock, impulsion and corrosion.
Due to the material is not resistant to alkali, amine, acids, dissolved in Chlorinated hydrocarbons aromatic solvents, so please make device far away from those chemical materials.
Please pay attention to prevent scratch on the meter box by edge tool.
The installation place should be cool and dry, please avoid the long time sun shining in order to extend its usage life.
