hex steel, hex mesh, hexsteel, hexmesh, refractory lining, flex metal refractory lining,
Hexsteel is a an unique honeycombed steel designed to provide excellent retention and reinforcement of thin wall refractories and fully complements dense hydraulic and chemically bonded refractories in resisting erosion.
Since Hesteel's flexibility allows it to be rolled, it easily conforms to circular shapes. It is ideal for lining Ducts, Furnaces, Reactor Vessels, Cyclones, Flue Gas Lines and other high temperature equipment of virtually any shape or configuration.
Application
Process plant which is subject to the passage of erosive gas streams, especially at high temperature, benefit by cladding with Hex metal infilled with erosion resistant refractories. Typical applications include Cyclones, Flue Gas Lines, Reactor Vessels, Wind boxes, Fan Casings, Burner Quails: in fact any vessel or section that is subject to erosion or abrasion.
|
Material |
Q235,Q345,304SS,310S,1Cr18Ni9Ti,0Cr13 |
|
Thickness |
1.0mm,1.2mm,1.5mm,1.8mm,2.0mm,2.5mm,3.0mm |
|
Height |
10mm,15mm,19mm,25mm,30mm,40mm,50mm,60mm |
|
Aperture |
40mm,45mm,50mm,60mm,70mm,80mm,100mm |
|
Panel size |
Standard size:0.96m*3.0m(according to the raw material size) |
