35KV 3000pf High Voltage Disc Capacitor

35KV 3000pf High Voltage Disc Capacitor thumbnail-1
35KV 3000pf High Voltage Disc Capacitor photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
MX
Place of Origin:
China
Model Number:
CT81
Contact Supplier Request Quote Chat Now
Shanghai Imax Electronic Co.,ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name MX
Place of Origin China
Model Number CT81

CT81 HV Disc Ceramic Capacitor 2KV~50KV,10pf~50000pf

CT81 High Voltage Disc Ceramic Capacitor, HighVoltage Disk Ceramic Capacitor, HV disc ceramic capacitor, 20KV radial discceramic capacitor, 30kv axial ceramic capacitor, 50kv axial disc ceramiccapacitor

Manufacture Supply CT81 High Voltage CeramicCapacitors

Application,

CO2 lasers

High voltage pulse generator

X-ray power supply

X-ray high voltage generator

NDT (Non-destructive testing)

Airport security equipment

High frequency & high voltage powersupplies

Medical power supply

Military

Rated Voltage: 1000V, 2000V, 3000V, 4000V, 5KV,6kv, 6.3KV, 8KV, 10KV, 12kv, 15KV, 20KV, 25KV, 27kv, 30KV, 35KV, 40KV, 50KV

Capacitance: 100pf (101), 120pf (121), 200pf(201), 220pf (221), 270pf (271), 330pf (331), 390pf (391), 470pf (471), 500pf(501), 510pf (511), 560pf (561), 680pf (681), 750pf (751), 1000pf (102), 1200pf(122), 1500pf (152), 2000pf (202), 2200pf (222), 2700pf (272), 3000pf (302),3300pf (332), 3500pf (352), 4000pf (402), 4500pf (452), 4700pf (472), 5600pf(562), 6000pf (602), 6800pf (682), 10nf (103), 20nf (203), 22nf (223), 47nf(473)

Characteristics:

Operating Temperature Range: -25C to +85C

Rated Voltage (V): 1 KV -50KVDC

Capacitance Range: 100pF -50,000pF

Temperature characteristic: N4700(DL), UJ, SL,YL, BN,Y5P, Y5R, X7E(X7E), X7F(X), X7R(X7R), Y5S(S), Y5T(D), Y5U(E), Y5V(F)

Test Voltage: 2 times of the rated voltage.

Dissipation Factor (tan): at 1 KHz, 1+-0.2Vrms, 25C

Y5P, Z5U: tan<=2.5%

Z5V: tan <=5%

Insulation Resistance: 10,000 M or 200 Mwhichever is the smaller

General Specifications:

6kv: 100pf, 470pf, 1000pf, 2200pf, 3300pf,4700pf, 10000pf

8kv: 18pf, 100pf, 500pf, 680pf, 1000pf,10000pf

250vac 8kvdc: 220pf, 470pf, 1000pf, 2200pf, 4700pf

10kv: 10pf, 22pf, 33pf, 50pf, 100pf, 135pf,220pf. 330pf, 500pf, 680pf, 1000pf, 2200pf, 3300pf, 4700pf, 5000pf, 10000pf

15kv: 30pf, 50pf, 100pf, 150pf, 220pf, 330pf,470pf, 500pf, 680pf, 1000pf, 1500pf, 2200pf, 3000pf, 3300pf, 4700pf, 10000pf

20kv: 20pf, 100pf, 110pf, 150pf, 220pf,330pf, 470pf, 500pf, 680pf, 1000pf, 1500pf, 2200pf, 3000pf, 5000pf, 6000pf, 10000pf

25kv: 500pf, 1000pf, 10000pf

30kv: 100pf, 150pf, 220pf, 330pf, 470pf, 500pf,680pf, 1000pf, 1500pf, 3300pf, 4700pf, 5000pf, 10000pf

35kv: 500pf, 1000pf, 1500pf, 2700pf, 3000pf,4500pf, 6000pf

40kv: 30pf, 100pf, 470pf, 4700pf, 6000pf

50kv: 30pf, 470pf, 500pf, 560pf, 750pf,1000pf, 10000pf

Alternative replacement and direct cross ofAVX, TDK, HVCA, CKE, Vishay, Morgan Ceramics and etc...
