YS Series Three Phase Asynchronous Motor

YS Series Three Phase Asynchronous Motor thumbnail-1
YS Series Three Phase Asynchronous Motor thumbnail-2
YS Series Three Phase Asynchronous Motor photo-1
YS Series Three Phase Asynchronous Motor photo-2
US$ 1 - 1 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
china coal
Place of Origin:
China
Model Number:
YS
Contact Supplier Request Quote Chat Now
Shandong China Coal Industrial Equipment Corp., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name china coal
Place of Origin China
Model Number YS

Quick Details
Brand Name: China coal
Model Number: YS SERIES
Type: Asynchronous Motor
Frequency: 50/60Hz
Output Power: 0.12-18.5kw
Protect Feature: Waterproof
Phase: Three-phase
Certification: CCC, CE AC
Voltage: 380V
Place of Origin: Shandong China (Mainland)
Efficiency: IE 2

Packaging & Delivery
Packaging Detail: Wooden cases or carton
Delivery Detail: Within 30 days

Specifications
Energy efficient, high starting distance, low noise, small vibration, high reliability, easy maintenance etc.

Products Induction

YS Series Aluminum Housing Three Phase Induction Motor adopts the latest design and high quality material and are conform to the IEC standard in function, appearance, output and other requirements.

The efficiency of YS motor meets EFF2 standard in E. U., and can reach the EFF1 standard if requested. YS motor has a lot of advantages including high efficiency, energy saving, low noise, little vibration, light weight, small volume, reliable operation, up-to-date appearance, convenient operation and maintenance.

YS motor is died casted into mounding shape by aluminum-alloy. The base foot can be removable. Various mounting types are available for YS motor.

YS motor is suitable for common working environment and machinery without special requirement, like air-compressor, pump, fan, medical apparatus and instruments, small machines etc.

Ys motor can be equipped with PTC.

Motor product labeling confirms to the following rules: Series Code + Frame Size + Iron Core Length No. + Motor Poles

Example: MS 90 S - 2

MS_means induction motor

90_the second part means the height of motor center (when the motor has no foot, it is same to motor with foot)

S_the third part means the base iron core length no. (S-Short Base, M-Medium Base, L-Long Base)

2_the forth part means the motor poles, this is a 2 poles motor, synchronous speed is 3000 r/min (50Hz); 3600 r/min (60Hz)

Service Conditions

--Ambient Temperature: -15° C~40° C

--Altitude: Not exceed 1000 Meter

--Rated Voltage: 380V or any voltage between 220-760V

--Rated Frequency: 50Hz/60Hz

--Protection Class: IP44, IP54, IP55

--Insulation Class: B/F

--Cooling Method: IC0141

--Working Duty: S1(Continuous)

-- Humidity: Lower than 90%

--Connection: Star-connection for up to 3Kw; Delta-connection for 4Kw and above












Model Output Voltage Current(A) Speed Eff Power Start
 torque
 Rated
 torque		 Start current Max.
torque
HP w (V) (r.p.m) (%) tactor (A) Rated
 torque
YS6312 0.25 180 380 0.53 2800 69 0.75 2.3 3.5 2.3
YS6322 0.33 250 380 0.68 2800 72 0.78 2.3 4 2.3
YS7112 0.5 370 380 0.96 2800 73.5 0.8 2.3 6 2.3
YS7112 0.75 550 380 1.35 2800 75.5 0.82 2.3 8 2.3
YS8012 1 750 380 1.75 2800 76.5 0.85 2.2 10.5 2.3
YS8022 1.5 1100 380 2.55 2800 77 0.85 2.2 16 2.3
YS90S-2 2 1500 380 3.44 2800 78 0.85 2.2 24 2.3
YS90L-2 3 2200 380 4.83 2800 80.5 0.86 2 34 2.3
YS6314 0.18 120 380 0.48 1400 60 0.63 2.4 3 2.4
YS6324 0.25 180 380 0.65 1400 64 0.66 2.4 4 2.4
YS7114 0.33 250 380 0.83 1400 67 0.68 2.4 5 2.4
YS7124 0.5 370 380 1.12 1400 69.5 0.72 2.4 7 2.4
YS8014 0.75 550 380 1.65 1400 73.5 0.73 2.2 9.5 2.4
YS8024 1 750 380 2.01 1400 75.5 0.75 2.3 12 2.4
YS90S-4 1.5 1100 380 2.75 1400 78 0.78 2.3 19.5 2.4
YS90L-4 2 1500 380 3.65 1400 79 0.79 2.3 25.5 2.4

YU6312 0.12 90 220 1.09 2800 56 0.67 1.5 12 1.8
YU6322 0.18 120 220 1.36 2800 58 0.69 1.4 14 1.8
YU7112 0.25 180 220 1.89 2800 60 0.72 1.3 17 1.8
YU7122 0.33 250 220 2.4 2800 64 0.74 1.1 22 1.8
YU8012 0.5 370 220 3.36 2800 65 0.77 1.1 30 1.8
YU8022 0.75 550 220 4.65 2800 68 0.79 1 42 1.8
YU6314 0.08 60 220 1.23 1400 39 0.57 1.7 9 1.8
YU6324 0.12 90 220 1.64 1400 43 0.58 1.5 12 1.8
YU7114 0.18 120 220 1.88 1400 50 0.58 1.5 14 1.8
YU7124 0.25 180 220 2.49 1400 53 0.62 1.4 17 1.8
YU8014 0.37 250 220 3.11 1400 58 0.63 1.2 22 1.8
YU8024 0.5 370 220 4.24 1400 62 0.64 1.2 30 1.8
YC7112 0.25 180 220 1.89 2800 60 0.72 3 12 1.8
YC7122 0.33 250 220 2.4 2800 64 0.74 3 15 1.8
YC8012 0.5 370 220 3.36 2800 65 0.77 2.8 21 1.8
YC8022 0.75 550 220 4.65 2800 68 0.79 2.8 29 1.8
YC90S-2 1 750 220 6.09 2800 70 0.8 2.5 37 1.8
YC90L-2 1.5 1100 220 8.68 2800 72 0.8 2.5 60 1.8
