Product model meaning 'example'"buyers can choose your favourite ones by the below"
YBK2-160M1-2
Y: Three-phase asynchronous motor
B: Flameproof
K: Coal mining
2: The second design
-160: Seat No. (centre-height)
M: Code of the seat length(Short, medium and long)
1: Core code (1, 2, type)
-2: Number of poles.
Product Description
YBK2 series flameproof three-phase asynchronous motor is for coal mine underground mining face of mechanical design special motor, base by steel plate welding forming, enclosures wind, connection box, insulation structure take measures, electrical performance, installation size, the power rating, etc YB2 motor with the same.
This series motors with explosion-proof GB3836.1-2000 "explosive gases with electrical equipment part 1: General requirements" and GB3836.2-2000 "explosive gases with electrical equipment part 2: Flameproof" d "standard of" regulation, made into flameproof Exd I. It is used in coal mine underground mining face.
Working atmosphere
1) ambient air temperature with the seasons change, but not exceeding 35deg (coal mine) or 40deg (factory), the lowest ambient air temperature of -15 degree
2) Altitude less than 1000m
3) ambient air relative humidity not more than 95% (90% when the temperature is 25 degree) (coal mine) or the minimum wet month and the average maximum relative temperature at the same time, the monthly average minimum temperature is not higher than 25 degree(factory )
The main technological parameters:
1. The rated voltage: 380 V and 660 V, 380/660 V, 660/1140 V
2. Rated frequency: Frequency 50 Hz
3. Protection level: IP55
4. Cooling way: IC411
5. Work week: S1
6. Insulation level: F
7. Installation forms: IMB3, IMB5, IMB35, etc
Congeneric Product(YB2 motor YL Motor Y2 three phase motor)
Packaging & Delivery
Packaging Detail: Standard export package
Delivery Detail: In 25 days
