Lighting Capacitor

Lighting Capacitor thumbnail-1
Lighting Capacitor photo-1
US$ 0.5 - 0.5 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Running
Place of Origin:
China
Model Number:
CBB61
Contact Supplier Request Quote Chat Now
Running Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Running
Place of Origin China
Model Number CBB61

Lighting Capacitor
1. Shell: ABS or polypropylene shell
2. Characteristics and Uses: The product has good stability, impact resistance current, overload and strong, low loss, high insulation resistance, long life rated, self-healing performance, built-in flame-retardant epoxy resin filling safe and reliable, capacitor leakage and liquid materials, nontoxic, environmentally and so on. Mainly used in refrigerators, air conditioners, motors, pumps, generators, home appliances, electronic products and so on.
3. Technical parameters:
Capacitance Range: 0.5μF ~ 40μF
Capacity Deviation: ± 5%, or by customer requirements.
Rated voltage: 125V ~ 500VAC, 50/60Hz
Operating temperature range: -40 ℃ ~ +70 ℃
Dissipation factor: ≤ 0.004 (20 ℃ .50/60Hz)
Resistance between terminal voltage: AC ≥ 1.75Un 5S no breakdown
Resistance between terminal voltage and the shell: AC ≥ 2000V 10S no breakdown
Insulation resistance: between terminations ≥ 3000MΩ.μF (20 ℃ .100 VAC); shell terminal and the Department between Rj ≥ 1000MΩ
Implementation of the standards: GB/T3667.1-2005 IEC60252-1: 2001.
