The FWG-P mainly consist of evaporating and condensing chambers,ejector equipped to achieve vacuum, fresh water pump for delivering distilled water to storage tank,relevant accessories built-in complete unit.
Sea water supply pump is only loose part which will be installed independently in proper position.
Control cabinet with embedded salinity meter directly fitted on the body of the unit and the cabinet also can be arranged separately in where convenient for operation.
Information below for yr reference,we reserve the rights to optimize our design without prior notices.
|
Mode(T/D) |
FWG-5 |
FWG-10 |
FWG-16 |
FWG-20 |
FWG-30 |
FWG-50 |
|
capacity |
5 |
10 |
16 |
20 |
30 |
50 |
|
Length(mm) |
770 |
970 |
970 |
1160 |
1400 |
1400 |
|
Width(mm) |
600 |
870 |
1150 |
1150 |
1250 |
1450 |
|
Height(m m) |
960 |
1150 |
1150 |
1415 |
1550 |
1550 |
|
Dry weight(kg) |
300 |
650 |
900 |
1150 |
1350 |
1450 |
|
Operation weight(kg) |
350 |
700 |
950 |
1250 |
1450 |
1600 |
Main features of plate type fresh water generator:
-wide range of production capacity(1~50D/T)
--Compact design for easy installation
--standard parts for convenient replacement by crews
---highly compatible to variety heating sources:
Steam heating block,hot water,thermal oil heating block
--high quality titanic plate,316LSS&Al-Bronze for other component.
