15 Inch High Performance Industrial Panel pc 3xRS232,1xRS485,2LAN,4USB
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
SUNPC
Place of Origin:
China
Model Number:
IPPC-Q150D-2R
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
12 Inch High Performance Industrial Panel PC Support I3I5I7 CPUNegotiableMOQ: 2 -
Atom D525 Fanless Embedded Computer BPC-D5205-FLNegotiableMOQ: 2
-
22 Inch Wide LCD Multitouch Industrial Panel PC IPC-222NegotiableMOQ: 2
-
10.4 Inch Open Frame Industrial LCD Monitor OPD-10HONegotiableMOQ: 2
-
15 Inch 7U Rack Mount Display Monitor RCM-15NegotiableMOQ: 2
Brand Name
SUNPC
Place of Origin
China
Model Number
IPPC-Q150D-2R
Product Description
We are a manufactuer and have our own factory, we provide many kinds of industrial panel pcs , such as panel mount industrial panel pc, rackmount industrial panel pc, high performance industrial panel pcs, from 8.4" to 19", and also provide industrial lcd monitor, fanless embedded computer,mini-itx motherboard ect
We are a manufactuer and have our own factory, we provide many kinds of industrial panel pcs , such as panel mount industrial panel pc, rackmount industrial panel pc, high performance industrial panel pcs, from 8.4" to 19", and also provide industrial lcd monitor, fanless embedded computer,mini-itx motherboard ect
Product Feature
1. 15" XGA TFT LCD Panel support 1024 × 768pixels
2. Intel Core i7/i5/i3/Pentium/Celeron CPU in 1155-pin
3. Front 6mm aluminum bezel with IP65 compliant
4. Front hardness glass protect screen
5. 4* COM, 1* LPT, 1*HDMI,1*DVI, 1 * VGA, 4 * USB, 1* GLAN, 1* LPT, 1* LINE-IN/OUT
6. 1* Mini PCIe slot,
7. Wireless LAN with antenna (option)
8. Panel ( Flush ) mount with clips
1. 15" XGA TFT LCD Panel support 1024 × 768pixels
2. Intel Core i7/i5/i3/Pentium/Celeron CPU in 1155-pin
3. Front 6mm aluminum bezel with IP65 compliant
4. Front hardness glass protect screen
5. 4* COM, 1* LPT, 1*HDMI,1*DVI, 1 * VGA, 4 * USB, 1* GLAN, 1* LPT, 1* LINE-IN/OUT
6. 1* Mini PCIe slot,
7. Wireless LAN with antenna (option)
8. Panel ( Flush ) mount with clips
Product Specification/Models
TFT Characteristics
Display Type 15XGA TFT LCD Pixel Number 1024x768
Pixel Pitch(RGB) 0.297*0.297 Contrast Ratio 700:1
Light Intensity 350 nits Viewable Angles 150°(H),135°(V)
Max Colors 16.2MB Response Time 8ms
MTBF 50,000hrs.
System Characteristics
Processor Intel Corei7/i5/i3/Pentium/Celeron CPU In 1555-pin Chipset Intel Q67
Memory 2x SO DIMM DDR31066/1333 SDRAM UP to 16GB. Graphic On CPU
Storage Space for 1x2.5" SATA HDD / SSD/ 1 compact flash card slot Audio Realtek ALC662,5.1 Channel surround Audio
USB Port 4 x USB2.0 Ethernet 100/1000M Ethernet
VGA Port 1 x VGA Connector DVI/HDMI 1xDVI,1xHDMI
Serial Port 4 x COM ( 3 x RS232,1 x RS232/422/485) Expansive Slot 1xMini PCIe
Watchdog Timer 255Levels,1-255sec.
Available Options
Touch Screen 5 Wire Resistive type Wireless LAN Meet IEEE802.11b/gstandard.
DC Power Input DC8-28V Speakers 2
I/O Connector
HDMI/DVI 1 x HDMI,1xDVI Lan 1 x 100/1000 Lanport(RJ-45))
VGA 1 x VGA USB 4 x USB2.0
Serial Port 4 x COM(3xRS232,1xRS232/422/485) Power Switch 1 x Power Switch
LPT 1 x LPT DCInput 1 x Lockable DC Input connector
Audio 1 x Lin-in/Lin-out/Mic-in
Mechanical and Environmental
Construction Aluminum front bazel and steel enclosure Storage humidity 10% to 90% non-condensing
Operating temperature 32°F~125°F(0°C to 50°C) Anti-Vibration 17 to 500Hz 1G PTP
Storage temperature -4°F~140°F(-20°C to 60°C) Dimensions(WxHxD 322x247.5x71mm
Anti-Shock 1g/peak(11ms) Weight Net: 6KG , Volume Gross:8.5 KG
Power Specification
Input 100~240VAC,50/60Hz Output DC19V@10A/190W,external ACPower Adapter with Lockable connector
Certificate&Approvals CE/FCC/ROHS
Ordering Information
IPPC-Q150D-2RH 15 "XGA Slim Line Panel Mount Industrial Panel PC, Support intel Core i7/i5/i3/Pentium/Celeron CPU, with 320G HDD,2G DDR3 RAM, DC19V power adapter
IPPC-Q150DT-2RH 15"XGA Slim Line Panel Mount Industrial Panel PC, Support intel Core i7/i5/i3/Pentium/Celeron CPU, with 15"touch screen, with 320G HDD,2G DDR3 RAM, DC19V power adapter
Optional:
Storage 16G SSD/32G SSD/8G CF card
Wireless LAN Wifi
Power supply DC8-28V
Speakers 2
TFT Characteristics
Display Type 15XGA TFT LCD Pixel Number 1024x768
Pixel Pitch(RGB) 0.297*0.297 Contrast Ratio 700:1
Light Intensity 350 nits Viewable Angles 150°(H),135°(V)
Max Colors 16.2MB Response Time 8ms
MTBF 50,000hrs.
System Characteristics
Processor Intel Corei7/i5/i3/Pentium/Celeron CPU In 1555-pin Chipset Intel Q67
Memory 2x SO DIMM DDR31066/1333 SDRAM UP to 16GB. Graphic On CPU
Storage Space for 1x2.5" SATA HDD / SSD/ 1 compact flash card slot Audio Realtek ALC662,5.1 Channel surround Audio
USB Port 4 x USB2.0 Ethernet 100/1000M Ethernet
VGA Port 1 x VGA Connector DVI/HDMI 1xDVI,1xHDMI
Serial Port 4 x COM ( 3 x RS232,1 x RS232/422/485) Expansive Slot 1xMini PCIe
Watchdog Timer 255Levels,1-255sec.
Available Options
Touch Screen 5 Wire Resistive type Wireless LAN Meet IEEE802.11b/gstandard.
DC Power Input DC8-28V Speakers 2
I/O Connector
HDMI/DVI 1 x HDMI,1xDVI Lan 1 x 100/1000 Lanport(RJ-45))
VGA 1 x VGA USB 4 x USB2.0
Serial Port 4 x COM(3xRS232,1xRS232/422/485) Power Switch 1 x Power Switch
LPT 1 x LPT DCInput 1 x Lockable DC Input connector
Audio 1 x Lin-in/Lin-out/Mic-in
Mechanical and Environmental
Construction Aluminum front bazel and steel enclosure Storage humidity 10% to 90% non-condensing
Operating temperature 32°F~125°F(0°C to 50°C) Anti-Vibration 17 to 500Hz 1G PTP
Storage temperature -4°F~140°F(-20°C to 60°C) Dimensions(WxHxD 322x247.5x71mm
Anti-Shock 1g/peak(11ms) Weight Net: 6KG , Volume Gross:8.5 KG
Power Specification
Input 100~240VAC,50/60Hz Output DC19V@10A/190W,external ACPower Adapter with Lockable connector
Certificate&Approvals CE/FCC/ROHS
Ordering Information
IPPC-Q150D-2RH 15 "XGA Slim Line Panel Mount Industrial Panel PC, Support intel Core i7/i5/i3/Pentium/Celeron CPU, with 320G HDD,2G DDR3 RAM, DC19V power adapter
IPPC-Q150DT-2RH 15"XGA Slim Line Panel Mount Industrial Panel PC, Support intel Core i7/i5/i3/Pentium/Celeron CPU, with 15"touch screen, with 320G HDD,2G DDR3 RAM, DC19V power adapter
Optional:
Storage 16G SSD/32G SSD/8G CF card
Wireless LAN Wifi
Power supply DC8-28V
Speakers 2
