10.4 inch open frame Industrial LCD Monitor OPD-10HO

Product Description
We are a manufactuer and have our own factory, we provide many kinds of industrial panel pcs , such as panel mount industrial panel pc, rackmount industrial panel pc, high performance industrial panel pcs, from 8.4" to 19", and also provide industrial lcd monitor, fanless embedded computer,mini-itx motherboard ect

Product Feature
10.4" open frame Industrial LCD Monitor OPD-10HO

1. 10.4" XGA TFT LCD Panel support 1024x768 pixels
2. Open frame structure with strengthen glass
3. Rugged construction and modularized design
4. Input signal : VGA input
5. 400 cd/m2 brightness
6. OSD control keys to optimize the display
7. AC 100-240V wide range external ac adapter
8. Meet standard VESA hole ( 75x75 mm), support desk top stand / wall mount / swing arm mounting


Product Specification/Models
TFT Characteristics
Display Type 10.4" XGA TFT LCD
Resolution
1024 x 768

Pixel Pitch(RGB)
0.20625x 0.20625 mm
Contrast Ratio
500 : 1

Light Intensity 400 cd/m2
Viewable Angles
70/70,60/60

Max Colors 262K
Response Time
25 ms

MTBF 50,000hrs.
Display Area(mm)
211.2x158.4 mm

Available Options

Touch Screen
Resistive type

Video input
AV input or VGA+DVI input

Power Specifications

Input
100~240VAC,50/60Hz

Output
DC12V@5A/60W,external AC adapter

Mechanical and Environmental

Construction
Heavy duty steel and aluminum front panel

Dimension (WxHxD)
260x190x40mm

Weight


Operating temperature
32 °F~113 °F (0 °C to 50 °C)
Storage temperature
-4 °F~140 °F (-20 °C to 60 °C)

Storage humidity
10% to 90%non-condensing
Vibration
17 to 500HZ 1G PTP

Anti-Shock
1G /peak( 11m sec)

Input Signals

RGB Signal
D-SUB 15p Connector( Female)

DC input
DC jack (2.0mm)

Audio input
3.5" jack

Certification and Approvals

Certificate & Approvals CE/ RoHS



Ordering Information

VGA+DVI input

OPD-10HO
10.4" Industrial Flat Panel Monitor with VGA input

OPD-10HO-TU
10.4" Industrial Flat Panel Monitor with VGA input ,with Touch screen and USB controller

OPD-10HO-TC
10.4" Industrial Flat Panel Monitor with VGA input ,with Touch screen and RS232 controller

AV input

OPD-10AHO
10.4" Industrial Flat Panel Monitor with VGA+ S-Video + AV input

OPD-10AHO-TU
10.4" Industrial Flat Panel Monitor with VGA+ S-Video + AV input, with Touch screen and USB controller

OPD-10AHO-TC
10.4" Industrial Flat Panel Monitor with VGA+ S-Video + AV input, with Touch screen and RS232 controller

DC-DC power
DC8~30V input power module



Application
industrial

Other Information
