Product Details
| Brand Name | JD | Place of Origin | China | |
| Model Number | JD-T8-0.6M-OC9 |
Product Description
Certification:CCC, CE, RoHS
High Performance 588MM DC 21 - 25 V 720 - 800 Lm T8 9W Cob LED Tube
The features of COB LED tube
Efficient and energy-saving: With high-performance constant-current power supply, conversion efficiency is greater than 90%, 60% energy saving, life span is up to 30000-50000 hours.
Stable Performance- Apply to AC85-265V 47-63Hz wide voltage, broad frequency input, AC conversed to DC, reducing LED decay, starting fast, no flicker, not easy to damage product under frequent turning on and off.
Environment friendly-Using new LED light source, no mercury, lead and other hazardous substance, no pollution to environment. It no ultraviolet and infrared and other rays, causing very low heat, no attraction to mosquitoes, very clean and healthy for indoor use. The product is recyclable, COB LED tube is being recognized as the green light in the twenty-first century.
Novelly design-COB LED tube , light full, soft, spectral purity, ultra-high brightness, high color-rendering index, is a new type of illumination products. Unique circuit design, using high-performance constant-current drive power, thereby achieving a highly efficient energy-saving purposes. The surface shell with special aluminum alloy, have good heat dissipation, beautiful appearance. installation and replacement. LED Products safe and convenient, is an ideal choice to replace the traditional fluorescent lighting.
Applications:
The product can be widely used for illumination in supermarket, hotel, showroom, home, meeting-room, factory, museum schoolhospital and so on.
Specifications:
|
Item No |
Dimensions (D×H) |
LED Type |
Input |
Power |
Power Type |
Power Factor |
Operating Temperature |
|
JDT8-0.6M-OC9 |
D26×L588 mm |
COB LED |
DC21-25V/ 400mA |
9W |
Outside isolate constant current power supply |
≥0.95 |
-20-60°C |
Optics Parameter
|
luminous flux |
Luminous efficiency |
Lux/1M |
Color Temp |
Color-Rendering Index (Ra) |
Illuminate Angle |
|
630-700Lm |
65-75Lm/W |
≥250Lx/1M |
6000±500K |
≥80 |
155° |
|
720-800Lm |
|||||
|
585-650Lm |
70-80Lm/W |
4000±300k |
|||
|
675-750Lm |
Dimension List(Unit:MM)
