Recyclable High Luminous 1198 mm 19W T8 DC 45 - 50V Cob LED Tube Lighting
- T/T L/C D/P D/A
- 7 days
You May Like
-
14 Watt 1120 - 1200Lm D26 * L894 mm DC 33 - 38 V Energy Saving Cob LED Tube
-
High Brightness 1198MM 1520 - 1600 Lm 16W Inside Power T8 Cob LED Tube Lighting
-
1498MM 70 - 80Lm / W 500mA 24W T8 High-performance Cob LED Tube Lights
-
DC 21 - 25 V 400mA 9W High Efficient T8 Ultra-high Brightness Cob LED Tube For Showroom
-
Environment Friendly 588 mm 50 / 60Hz 9W T8 720 - 800Lm Cob LED Tube Lightig
-
High Luminous 1498 mm DC 45 - 50 V 24W T8 Cob LED Tube Lights For Indoor
Product Details
Brand Name | JD | Place of Origin | China | |
Model Number | JD-T8-1.2M-OC19 |
Product Description
Certification:CCC, CE, RoHS
Recyclable High Luminous 1198 mm 19W T8 DC 45 - 50V Cob LED Tube Lighting
19W COB LED T8 TUBE(Outside Power Supply)
The features of COB LED tube
Novelly design-COB LED tube , light full, soft, spectral purity, ultra-high brightness, high color-rendering index, is a new type of illumination products. Unique circuit design, using high-performance constant-current drive power, thereby achieving a highly efficient energy-saving purposes. The surface shell with special aluminum alloy, have good heat dissipation, beautiful appearance. installation and replacement. LED Products safe and convenient, is an ideal choice to replace the traditional fluorescent lighting.
Efficient and energy-saving: With high-performance constant-current power supply, conversion efficiency is greater than 90%, 60% energy saving, life span is up to 30000-50000 hours.
Stable Performance- Apply to AC85-265V 47-63Hz wide voltage, broad frequency input, AC conversed to DC, reducing LED decay, starting fast, no flicker, not easy to damage product under frequent turning on and off.
Environment friendly-Using new LED light source, no mercury, lead and other hazardous substance, no pollution to environment. It no ultraviolet and infrared and other rays, causing very low heat, no attraction to mosquitoes, very clean and healthy for indoor use. The product is recyclable, COB LED tube is being recognized as the green light in the twenty-first century.
Applications:
The product can be widely used for illumination in supermarket, hotel, showroom, home, meeting-room, factory, museum schoolhospital and so on.
Specifications:
Item No |
Dimensions (D×H) |
LED Type |
Input |
Power |
Power Type |
Power Factor |
Operating Temperature |
JDT8-1.2M-OC19 |
D26×L1198 mm |
COB LED |
DC45-50V/ 400mA |
19W |
Outside isolate constant current power supply |
≥0.95 |
-20-60°C |
Optics Parameter
luminous flux |
Luminous efficiency |
Lux/1M |
Color Temp |
Color-Rendering Index (Ra) |
Illuminate Angle |
1330-1400Lm |
65-75Lm/W |
≥450Lx/1M |
6000±500K |
≥80 |
155° |
1520-1600Lm |
|||||
1235-1300Lm |
70-80Lm/W |
4000±300k |
|||
1425-1500Lm |
Dimension List(Unit:MM)
