Fujikura Fusion Splicer FSM-60S

Description

Fujikura fusion splicer (FSM-60S) with CT-30A cleaver, 4.1" color screen, standard accessories, Multiple foreign languages menu is optional.

Features
1. Rugged construction providing shock, dust and moisture resistance
2. Dual monitor position with automatic image orientation
3. Automatic arc calibration and fiber identification
4. User-selectable fiber clamping method - sheath clamp or fiber holders
5. Auto-start tube heater feature
6. Color LCD display with anti-reflective coating for excellent visibility in bright sunlight
7. Simultaneous battery charge and splicer operation ADK Technology
8. Long life battery (up to 160 splice/heat cycles per charge)
9. Detachable work table incorporated into the transit case
10. Data and video download software included; Software upgrade available via the internet
11. Green friendly-RoHS & WEEE compliant

Parameter

Item  Specification

Applicable Fibers SM(ITU-T G.652), MM (ITU-T G.651), DS (ITU -T G.653), NZDS (ITU-T G.655) and other single mode fiber including ITU-T G.657 fiber

Fiber count Single

Applicable fiber dimensions Cladding Diameter: 80μm to150μm  Coating Diameter:100μm to 1,000μm

Fiber setting and cleaved length Sheathe clamp A (standard) : For coating dia. up to 250um (8 to 16mm cleave), coating dia. Of over 250um (16um cleaver) Sheathe clamp B (option) :For coating dia. up to 1000um (8 to 16mm cleave) Sheathe clamp C (option) :For 900um dia. Loose tube fiber (8 to 16mm cleave) Fiber holder (option) :FH-60-250 and FH-60-900 (10mm cleaver)

Splicing modes 100 preset and user programmable modes

Typical average splice loss 0.02dB with SM, 0.01dB with MM, 0.04dB with DS, 0.04dB with NZDS (Measured by cut-back method relevant to ITU-T and IEC standards)

Return loss >>60dB

Splicing time Typical 9 sec. with SM FAST, 10sec. with SM AUTO and 13sec with AUTO  modes with standard SM (ITU-T G.652)

Splice Loss estimate  Available

Attenuation splicer function Intentional high splice loss of 0.1dB to 15dB (0.1dB step) can be made for an in-line fixed attenuator

Tube heater / heating time Built-in tube heater with 30 heating modes.Typical 30 seconds with FP-03 sleeve

Applicable protection sleeve  60mm, 40mm and Fujikura FPS01 series.

Storage of splice result The last 2000 results to be stored in the internal memory

Tension test 1.96 to 2.25N

Operating condition 0 to 5,000m above sea level, 0 to 95%RH and -10 to 50 degC and up to  15m/s wind velocity, respectively

Storage condition 0 to 95%RH and -40 to 80 degC respectively. Battery:-20 to 30 degC for long term

Dimensions 136W x 161D x 143H (mm) / 5.3W x 6.3D x 5.6H (inches)

Weight 2.3 kg (5.1 lbs) with AC adapter ADC-13; 2.7kg with BTR-08

Viewing method Two CMOS cameras and 4.1 inch TFT color LCD monitor

Fiber view and magnification 300X for single X or Y view, or 187X for X and Y view

Power supply Applicable voltage from 100 to 240V AC or 10 to 15V DC with ADC-13, 13.2V DC with BTR-08 battery

No.of splice cycles with battery Typical 160 cycles (splice / tube heat) with BTR-08

Electrode life 2500 arc-discharges

Terminals USB 1.1 (Mini-B type) connector for PC communication. 6-pin Mini-DIN connector for HJS-02/03 or SH-8 power supply
