Chinese Fusion Splicer FSP-100

Description

Chinese optical fiber fusion splicer, 5 inch color screen, standard accessories. Multiple language menu options, without cleaver.

Features
1. Fiber core can be display clearly
2. Single X or Y view and X & Y view simultaneously
3. Auto check quality of cleaved end face
4. Auto select best splicing program
5. 9 seconds splice time and 30 seconds heat time
6. Small bulk and light weight
7. 5 inch color LCD monitor with clear digital image display
8. Simple operation menu

Parameter

Item Specification

Applicable fiber SM MM DS NZDS

Fiber cleaved length 8~16mm

Fiber diameter Cladding diameter:80~150um Coating diameter:100~1000um

Fiber count Single

Fiber aligning method Core aligning

Return loss >60db

Actual average splice loss 0.02db-SM;0.01db-MM; 0.04db-DS;0.04db-NZDS

Splicing mode Auto

Typical splicing time 9 sec for standard SM fiber

Tube typical heating time 30sec

Protection sleeve length 40mm, 60mm

Storage of splice result 5000, 3 parameter per result

Tension 2N

Fiber magnification 400X(X or Y view) &200X(X or Y view)

Electrode life 2500

No. of splice/heating with battery 130 cycles

Image change over The fiber image can be turned out

Display screen 5 inch color LCD monitor

Terminal management RS232 port

Power supply AC100~240V with adaptor and with 6600mAH Li-battery

Operating temperature 0~5000m above sea level -10~50 °C

Dimension 150x150x160mm

Weight 3.52kg including battery

Application

SM(ITU-T G.652), MM(ITU-T G.651),

DS(ITU G.653),NZDS(ITU-T G.655)

Dimension

150x150x160mm

Minimum Order

1pcs

Weight

3.52kg

Delivery Time

5~7days

Packaging

By standard export carton

Supply Ability

1000pcs/month
