Fusion Splicer（FTTH) for Drop Cable and Pathcord FSP-500

Name: Fusion Splicer（FTTH) for Drop Cable and Pathcord FSP-500
Brand: YOUXIN
SKU: 147573204
Availability: InStock

Ningbo Youxin Optic-Electronic Technology Interprise

Fusion Splicer（FTTH) for Drop Cable and Pathcord FSP-500 thumbnail-1

Fusion Splicer（FTTH) for Drop Cable and Pathcord FSP-500 thumbnail-2

Fusion Splicer（FTTH) for Drop Cable and Pathcord FSP-500 thumbnail-3

Fusion Splicer（FTTH) for Drop Cable and Pathcord FSP-500 photo-1

Fusion Splicer（FTTH) for Drop Cable and Pathcord FSP-500 photo-2

Fusion Splicer（FTTH) for Drop Cable and Pathcord FSP-500 photo-3

Negotiable MOQ: 1 Case (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

YOUXIN

Place of Origin:

China

Model Number:

FSP-500

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name YOUXIN

Place of Origin China

Model Number FSP-500

Fusion Splicer(FTTH) for drop cable and pathcord, with USB and VGA interface, 5.7 inch color screen, standard accessories. Multiple language menu options, with cleaver.

Features: Download DOC: $\"fusion$ fusion splicer FSP-500

◇ FTTH is environment, can be used in normal optical fiber engineering

◇ Accurate fiber core alignment, guarantee in the low loss

◇ Small volume, light weight, including the battery only 2.8 kg

◇ 8 seconds welding, heat shrinkable 30 seconds

◇ X/the Y axis shows at the same time, magnified 304 times

◇ Can be set to close wind cover automatically start welding, closed heating cover heat shrinkable start automatically

◇ Real-time discharge correction, do not need to adjust the parameters

◇ Electrode life is long, discharge is as high as 4000

◇ USB and VGA port

◇ 5.7 inch high-definition digital display on the LCD panel

◇ Built-in super capacity of lithium battery, can be completed in 220 times and heating

◇ Real-time accurate says the battery surplus

Description

The fiber fusion splicer(FSP-500 )is FTTH fibersplicing machines is a new design of the optical fiber in equipment. In thelight of the special FTTH environment.
In fiber application: This fiber fusion splicer light body and the fine designin the even if narrow work environment also can ease; Our this fiber fusionsplicer has Novel light, and the fiber fusion splicer can provide fine imagingsystem and pure digital design makes the image display is more exquisite,clear. The embedded real-time operating system provides the friendly interfaceand more rich function; The built-in super capacity for long time highperformance of lithium battery field work provides reliably.
Temperature, humidity and pressure real-time compensation system has greatlyimproved the equipment adapt to bad environmental change ability, for indifferent get low loss in the environment of the consistency of the provide aguarantee.
Parameter

Applicable Fiber	SMF(ITU-T G. 652), MMF(ITU-T G. 651), DSF(ITU-T G. 653), NZDSF
Average Splicing Loss	0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0.04dB(NZDS)
Return Loss	< -60dB
Operation Mode	Auto, Half auto, Manual
Align Mode	Advanced PAS align mode.
Fiber Diameter	clad diameter: 80µ m∼ 150µ m, coating diameter: 100µ m∼ 1000µ m
Cleave Length	8~16mm(coating diameter< 250µ m), 16mm(coating diameter 250∼ 1000µ m)
Magnification	Vertical 152times, horizontal 304times.
Image Display	5.7´ 640× 480 LCD.
Pull Test	Standard 2N(optional).
Pyrocondensation Tube	40mm, 60mm and a series of micro Heat-Shrinkable Tubing.
Battery Capacity	Typically splice 220 times, charging for 3.5 hour(available when charge).
Battery Lifetime	Cycle life up to 300∼ 500 times, replaceable.
Electrode Lifetime	> 4000 times, replaceable
Lighting for Construction	Built-in super High-brightness LED supply convenient for night work
Ports	USB, VGA
Power Supply	Built in 11.1V Lithium Ion Battery. AC adopter(input AC100∼ 240, output DC13.5V/4.5A)
Environment Adaptation	Temperature range: -10º C∼ 50º C; Humidity: 95%RH(40º C), no condensing); Altitude: 0∼ 5000m
Size	L× W× H=160× 150× 140(mm)
Weight	2.3kg(no battery ), 2.8kg (including battery)
