Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Communication Cable > Figure 8 Self-supporting Cable GYTC8S
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
YOUXIN
Place of Origin:
China
Model Number:
GYTC8S
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Figure 8 Self-supporting Cable GYXTC8YUS$ 1 - 1MOQ: 5 Pieces -
Aluminum Tape Layer Loose Tube Outdoor Cable GYTANegotiableMOQ: 1 Piece
-
Double Armored and Double Sheathed Outdoor Cable GYTA53NegotiableMOQ: 1 Piece
-
Single Armored and Double Sheathed Outdoor Cable GYTY53NegotiableMOQ: 1 Piece
-
Dielectric Loose Tube Cable GYFTYNegotiableMOQ: 1 Piece
Brand Name
YOUXIN
Place of Origin
China
Model Number
GYTC8S
Figure 8 self-supporting cable GYTC8S, 2~144 fibers, central strength member (steel), jelly filled, fiber contained loose tube and PP filler (if necessary) stranded, water blocking jelly, longitudinally covered by copolymer coated steel tape, PE outer sheath, fig 8 type, the suspension line (1.2x3=3.6mm), 7 steel wires stranded together. G652D SM fiber, detailed specification on your request.
Features
◇Low dispersion and attenuation
◇ Proper design, precise control for fiber excess length and distinct stranding process
render the cable excellent mechanical and environmental properties
◇ With small cable diameter, light cable weight, easily to lay
◇ The armoring of corrugate steel tape make cable have nice properties of moisture resistance and crush resistance
◇ Operating Temperature : -40~+60 ℃
Description
Loose tube style, optical fiber cable with metallic central strength member of steel wire/strand and moisture barrier inner sheathed. Cable protected by a black PE oversheath, suitable for duct or aerial application. Tubes contain optical single-mode or multimode fibers color coded as per color coding scheme.
Parameter
|
Fiber count
|
Cable dia.(mm)
|
Cable net weight(Kg/km)
|
Min. bending radius(D=diameter)
|
Min. tensile strength(N)
|
Min. crush pressure(N/100mm)
|
|||
|
Static state
|
Dynamic state
|
Short term
|
Long term
|
Short term
|
Long
|
|||
|
term
|
||||||||
|
-30
|
10.1x19.3
|
205
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
|
32-36
|
10.6x19.9
|
235
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
|
38-60
|
11.4x20.8
|
236
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
|
62-72
|
12.2x21.6
|
271
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
|
74-84
|
13x22.4
|
295
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
|
86-96
|
13.8x23.2
|
312
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
|
98-108
|
15x24.4
|
332
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
|
110-120
|
15.4x24.8
|
352
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
|
122-132
|
16.2x25.6
|
382
|
10D
|
20D
|
6000
|
|
3000
|
1000
|
|
134~144
|
17x26.4
|
396
|
10D
|
20D
|
6000
|
3000
|
3000
|
1000
|
