GSM1800 / PHS Directional Yagi Antenna 1710- 1880 MHz, 15 dBi, SMA Female Connector
Application:
● GSM1800/PHS System
● Repeater station system
● Long distance telecommunication
Feature:
● High Gain
● Aluminum Alloy frame
● Full day for working
● Optimized dimension
● Optional installation H or V
Specification
|
Model NO |
RSY-1710-1880-15 |
|
Electric Spec |
|
|
Frequency rang-MHz |
1710～1880 |
|
Bandwidth -MHz |
170 |
|
Gain -dBi |
15 |
|
element |
13 |
|
beam width -° |
H:40 V:37 |
|
F/B Ratio-dB |
≥16 |
|
VSWR |
≤1.5 |
|
Input Impedance-Ω |
50 |
|
Polarization |
Horizontal or Vertical |
|
Max power -W |
100 |
|
Lightning protection |
DC ground |
|
Connector model |
SMA female or others |
|
Mechanical Specification |
|
|
Size -mm |
570*90*44 |
|
Cable length-m |
0.3 |
|
Antenna weight-kg |
0.33 |
|
Working Temperature -°c |
-40～60 |
|
Rated Wind Velocity-m/s |
60 |
|
Clamp |
U |
|
Pole diameter -mm |
Φ40～Φ50 |
