Certification:ROSH
Portable High Gain Outdoor Wireless 12 DBi Directional 433MHZ Yagi Antenna
Application:
● 433MHZ RIFID System
● 433MHZ Wireless Access system
● Village to Village project
Feature:
● High Gain
● Aluminum Alloy frame
● Full day for working
● Optimized dimension
● Optional installation H or V
Specification
|
Model NO |
RSY-433-12 |
|
Electric Spec |
|
|
Frequency rang-MHz |
433±10 |
|
Bandwidth -MHz |
20 |
|
Gain-DBi |
12 |
|
element |
6 |
|
beam width -° |
H:42 V:38 |
|
F/B Ratio -dB |
≥16 |
|
VSWR |
≤1.5 |
|
Input Impedance-Ω |
50 |
|
Polarization |
Horizontal or Vertical |
|
Max power -W |
100 |
|
Lightning protection |
DC ground |
|
Connector model |
N female or others |
|
Mechanical Specification |
|
|
Size -mm |
770*350*80 |
|
Cable length-m |
0.3 |
|
Antenna weight-kg |
0.55 |
|
Working Temperature -°c |
-40～60 |
|
Rated Wind Velocity-m/s |
60 |
|
Clamp |
U |
|
Pole diameter -mm |
Φ40～Φ50 |
