Long Distance Point To Point 16 DBi 3G Directional Yagi Antenna 1920- 2170 MHz 15 Element
- T/T L/C D/P D/A
- 7 days
You May Like
-
Portable High Gain Outdoor Wireless 12 DBi Directional 433MHZ Yagi Antenna
-
550 - 750 MHz Directional Yagi TV Antenna 12 DBi With 9 Element, F Female Connector
-
824 - 960 MHz 12 DBi DC Ground GSM Directional Yagi Antenna With 8 Element, U Clamp
-
2400 - 2483 MHz Long Range 16DBI 2.4GHZ Directional Yagi Antenna For Wireless Adapter
-
Aluminum Alloy Long Distance Directional Yagi GSM 900 /1800, PHS Antenna 12 DBi
-
Outdoor Horizontal / Vertical Directional 1.2GHZ Yagi Terminal Antenna 1100 - 1300 MHz
Product Details
| Brand Name | Runshine | Place of Origin | China | |
| Model Number | RSY-3G-16 |
Product Description
Certification:ROSH
Long Distance Point To Point 16 dBi 3G Directional Yagi Antenna 1920- 2170 MHz 15 Element
Specification
|
Model NO |
RSY-3G-16 |
|
Electric Spec |
|
|
Frequency rang-MHz |
1920-2170 |
|
Bandwidth -MHz |
250 |
|
Gain -dBi |
16 |
|
element |
15 |
|
beam width -° |
H:30 V:30 |
|
F/B Ratio-dB |
≥16 |
|
VSWR |
≤1.5 |
|
Input Impedance-Ω |
50 |
|
Polarization |
Horizontal or Vertical |
|
Max power -W |
100 |
|
Lightning protection |
DC ground |
|
Connector model |
SMA female or others |
|
Mechanical Specification |
|
|
Size -mm |
590*84*44 |
|
Cable length-m |
1 |
|
Antenna weight-kg |
0.32 |
|
Working Temperature -°c |
-40～60 |
|
Rated Wind Velocity-m/s |
60 |
|
Clamp |
U |
|
Pole diameter -mm |
Φ40～Φ50 |
Feature:
● High Gain
● Aluminum Alloy frame
● Full day for working
● Optimized dimension
● Optional installation H or V
Application:
● 3G System
● Point to Point system
● Long distance terminal antenna
