Cell Type |
Monocrystalline silicon |
|
Cell Size(mm) |
125x125 |
|
No.of Cell & Connections |
91(7x13) |
|
Dimension(mm) |
1705x940x50 |
|
Weight(KG) |
20.5 |
|
Electrical Characteristics |
|
|
Model |
SY-220M |
|
Maximum Power at STC(Pm) |
220W |
|
Open circuit voltage(Voc) |
55.33V |
|
Short circuit current(Isc) |
4,99A |
|
Voltage at P maxt (Vmp) |
45.86V |
|
Current at P maxt (Imp) |
4.58A |
|
(STC:Irradiance 1000W/,25 AM1.5) |
|
|
Limits |
|
|
Maximum System Voltage |
1000VDC |
|
Operating Temperature |
(-40)~(+90) |
|
Temperature Coefficients |
|
|
NOCT |
45±2 |
|
Temperature Coefficient of Isc |
±0.05%/ |
|
Temperature Coefficient of Voc |
-0.34%/ |
|
Temperature Coefficient of Power |
-0.5%/ |
|
Power tolerance |
±3% |
|
Construction |
|
|
Front |
High-transmission low-iron tempered glass |
|
Back |
TPT |
|
Encapsulant |
EVA |
|
Frame |
Aluminum |
|
Certification |
CE ISO9001 |
|
Warranty |
|
|
5Years products warranty,and 10 year 90% of power,25 years 80% of power |
|
