Peak Power (Pmax) |
(W): |
90 |
|
Production Tolerance |
(%) : |
3 |
|
Open Circuit Voltage (Voc) |
(V): |
18 |
|
Short Circuit Current (Isc) |
(A): |
5 |
|
Maximum Power Voltage (Vmp) |
(V): |
21.24 |
|
Maximum Power Current (Imp) |
(A): |
5.5 |
|
Maximum System Voltage |
(VDC): |
1000 |
|
Solar Cell Type |
Poly |
|
|
Solar Cell Quantity |
36(156*104mm )_2/3 |
|
|
Solar Cell Efficiency |
16% |
|
|
|
|
|
|
Operating Temperature Range |
- 40°C~+85°C |
|
|
Wind Resistance |
2400Pa |
|
|
Allowable Hail Load |
225G steel ball fall down from 1M height |
|
|
Surface Maximum Load Capacity |
60m/s ( 200kg /sq.m) |
|
|
|
|
|
|
Length |
1000mm/39.37" |
|
|
Width |
680mm/26.78" |
|
|
Depth |
35mm/1.38" |
|
|
Weight Per Piece |
8.2KGS |
|
|
Outer Packing Size(2PCS/CTN) |
102*71*8.5CM |
|
|
Total Packing G.W |
18KGS |
|
|
AII technical data at standard test condition |
||
|
AM=1.5 E=1000W/M2 Tc=25°C |
||
|
Performance warantty: 90% output for 12years and 80% output for 25years |
||
