Broadcast Series Outdoor SMD

SMD Technology (3 in 1)
The surface mount device (SMD) Technology, also known as
the 3 in 1 Technology, provides full-color capability from within a
single LED package, making every package a standalone pixel.
Required viewing distances are reduced and the quality of
the image is optimized because the red, green and blue light
blends into the package, rather than from neighbouring red,
green and blue LEDs.
Independent Packaging of
Power Supplies
All power supplies are packaged independently from the
cabinet, which makes it very simple to maintain and
replace the power supplies.
High Stability
• CE or UL certified power supplies made by Meanwell are
applied.
• All PCB boards in the Pledco Broadcast Series system are
UL approved.
• UL approved power cables, signal cables and Phoenix
connectors make our screens even more reliable.
• High refresh rates enable our screen to display flicker-free
video images including hi-definition live video inputs.
Easy to Install and Maintain
With a handle at the back of cabinet, it is very easy to
install and maintain the screen.
Labor-saving Delivery Method
The Broadcast Series Outdoor SMD display can be packaged
and shipped in large sections. Most of the wirings have already
been done in the factory, so the client only has to plug in a few
signals and power cables. This will save an enormous amount of
time and labor cost for the client.
Unparalleled Heat Dissipation
Heat generated by electronic components on the circuit
board is dissipated to the open air directly via the attached
aluminum rear plate. Extraordinary thermo-stability and
environment-adaptability is observed.

 Product Features :

Levels of gray & Total colors:Full color ,65536 levels of gray for each color,   over 281 billion colors

Frequency of Renewal:60Hz,Over 1000 - 12000 frames/sec standard available, higher refresh rates on demand

Auto Dimmer:Available.

Ingress protection:Display front an back side IP67, Power Supply Unit IP54

rive methode:Static constant current, 16bit

Control communication:Ethernet TCPIP, RS232, RS485, USB, Optional: Optical fiber / 3G / GPRS / Artnet / NTCIP

SMD Pixel specification

SMD brand brand:Cree packaged by Cotco or Nichia packaged by Nichia

Chip model: 5050

Physical pixel pitch:16mm

SMD Pixel Size & Configuration: 16mm 3-in-1

Pixel Density:15625 by Square meter 10000 by Square meter 5625 by Square meter 3906 by Square meter

Total weight per tile:2.7g without power supply, 4kg with power supply

Basic tile size:320mm x 320mm

Brightness: 6000 cd/m2

Brightness control:100 levels manual and 8 levels of automatic brightness control available, light sensor for automatic control available

Viewing angle:120 degree

Control System:Synchronous or Asynchronous available, depending on project requirement

Basic Cabinet Size:1280mm x 320mm (Custom configuration available)

Total weight:18Kg per cabinet, 45kg per square meter

Cabinet Color:Black, custom color available

Single / Double Face:Single and double face available

Material:Die cast aluminum, Aluminum, Stainless steel

Maintenance:Maintenance from back side, front maintenance available

Electrical and operation specifications

Maximum power consumption / SQM:350W

Average power consumption / SQM:177W

Power Required:AC 90V-250V at 47~64HZ

Auto Power On/O:Yes
