2 & 3 Wave Side Skip Guardrail Forming Machine With 12mm Wallboard Chain Drive

2 & 3 Wave Side Skip Guardrail Forming Machine with 12mm Wallboard Chain Drive

Applications:

It is used for expressway anti-collision guard rails and columns.

Specifications:

1.Leak frame load-bearing:4T

2. Rack: welding with 300H steel

3. The form of forming machine guiding filling: side skip

4.The form of forming machine: chain drive with wallboard type,  the thickness of wallboard is 12mm.

5. Diameter of Shaft is: 72mm

6.Chain: 0.6 inch single row

7. Main motor power:3kw double pole reduction box

8. Forming Speed: 8m/min

9. Number of tracks: 11 tracks

10. Roller material: high grade 45#steel

11 Hydraulic station power: 3kw

12 Hydraulic station oil pump: gear pump

13 Cutting type: hydraulic cut

14 Forming Cutting blade: Cr12

15 Heat treatment on cutting blade: HRC58°-60°

16 Thickness of coil sheet: 0.3-0.8mm

17 Coil width of material: 1000mm

18 Index error of length: ±2mm

19 Controlling system: PLC

20 Voltage: 380V 3phase 60Hz or at buyer’s requirement

Material of main equipment:

Roller material: high grade NO.45 forged steel,  plated hard chrome on the surface of roller with thickness 0.05mm.

Active shaft material: high grade NO.45 carbon wrought steel at diameter 72mm.

Cutting blade: Cr12 mould steel with quenched treatment.

Description:

This equipment is a specialized machine set for the guardrail cold roll forming machine. It is designed and produced according to the requirements of our customers. It is belong to non-standard product.

The first step is to put raw material on a cart, the cart will lift roll material up to the rack automatically. Hydraulic spading feeds the material into straightener, and enter into main machine. Die of main machine will progressively form to reach desired dimensions. Straightening device will help to eliminate internal stress to ensure flatness of products. Cutter will cut a intented length. Finally, the finished products will be moved away from the receiving platform.

Competitive Advantage:

1.Automatic roll forming machine

2.High quality
3.Factory direct price
4.Design by COPRA@ software from Germany

5.On time delivery

6.Good service
