20M IR Working Distance Dome Infared Camera With IR LED : 8X12PCS

Name: 20M IR Working Distance Dome Infared Camera With IR LED : 8X12PCS
Brand: VEACAM
SKU: 147118846
Availability: InStock

Negotiable MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

VEACAM

Place of Origin:

China

Model Number:

CE,FCC,RoHS

Veacam Electronics Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name VEACAM

Place of Origin China

Model Number CE,FCC,RoHS

Delivery Time:3-10 Days,Depends on Quantity
Certification:VCD20E

20M IR Working Distance Dome Infared Camera with IR LED : ￠8X12PCS

Features:
2.5' Plastic IR Dome Camera
3.6 mmLens(6mm Optional)
SONY /SHARP Color CCD
LED: ￠5X21PCS
20M IR Working Distance

Model	VCD20E11	VCD20E10	VCD20E9	VCD20E7	VCD20E5	VCD20E4	VCD20E1
Image Sensor	1/3' SONY CCD	1/3' SONY CCD	1/3' SONY CCD	1/3' SONY CCD	1/3' SONY CCD	1/3' SONY CCD	1/4' SHARP CCD
Horizontal Resolution	Effio 700TV Lines Low Illumination, OSD, ATR, 2D-NR	Effio 650TV Lines Low Illumination, DWDR, OSD	600TV Lines Low Illumination	540TV Lines Low Illumination	480TV Lines	420TV Lines
Pixels	PAL:976 (H)× 494(V) NTSC :976 (H) ×582 (V)	PAL:795 (H)× 596(V) NTSC :811 (H) ×508 (V)		PAL:752(H)×582(V), NTSC:768(H)×494(V)		PAL:500(H)×582(V) NTSC:510(H)×492(V)
TV System	PAL/NTSC
IR LED	￠8X12PCS
IR Series Distance	20 M
Lens	4-9mm Manual Zoom Lens 2.8-12mm is Optional
Sync System	Internal
IR Status	Under 10 Lux By CDS
Usable Illumination	0.001Lux/F2.0				0.0005Lux/F2.0		0.01Lux/F2.0
IR Power On	CDS Auto Control
S/N Ratio	≥65dB (AGC OFF)	≥54dB (AGC OFF)			≥48dB (AGC OFF)
Gamma Correction	0.45
Video Out	Composite Signal (1.0Vp-p, 75Ω)
Scanning System	PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec
Electronic Shutter Time	Auto:PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100, 000Sec
Operation Temperature	-10℃ ~ +50℃ RH95% Max
Storage Temperature	-20℃ ~ +60℃ RH95% Max
White Balance	Auto
Power Source	DC12V 450mA
Dimension	73(H)*94(D) mm
Weight	650g
