1.5V Rechargeable Alkaline Battery Charging Method AC-1008

1.5V rechargeable alkaline battery charging method AC-1008

A. Put 1.5V rechargeable alkaline battery into the charging slots, battery can be used after the led turn green, If the Charging time exceed 12H and LED still light red, don’t worry, you can use the battery.

B. If Not anxious to use the battery , Do not take out the battery from slots before the led turn green, in order to avoid charger misjudge the charging time and influence the charging effect.(Special Note: Pls ensure the Alkaline battery with energy when you store it and not use. In this case, the battery will get a better charging effect.)

C. Take out the full charged battery from the charging slots in time. Do not let the battery stay in the slots when not charging to avoid the battery leakage.


New battery for First use:
A. Put the battery into the charging slots, if the led light green, it shows the energy of battery is full, it need not charging.

B. When the led light red after the new battery was put into charging slots, it shows the Battery in the natural environment have the phenomenon of self-discharge, Add battery power with a larger electrical power(Digital Cameras, MP3 and so on)maybe displayed of The battery is dead, lack of electricity, or electrical item can not be used, in this case, do not use the battery(direced use may lead to excessive battery discharge, it will influence the charging effect of battery), you can use battery after it was fully charged, the new battery self-discharge is a normal phenomenon, just do some self-discharge and charging it.

Introduction

Applied to AA/ AAA 1.5V rechargeable alkaline battery

And Ni-MH /Ni-Cd Battery.

4 independent charging channels, Intelligent

Control Protection,

Especially applies to 1.5V AA/AAA of Digital

Cameras, Walkman, MP3, MP4, Repetition machine,

Toy and so on.

How to use

Put the battery into the charging channel according to the correct polarity symbol, then, connect the charger with power supply, LED light red when charging, after the battery was full charged, LED will turn green.



Charging time

Normally, the battery will be fully charged after 15 hours, but the charging time depend on the capacity of battery, the charger will stop charging after a Max. time 30 hours.

Specifications
Input:AC100V-240V, 50Hz-60Hz
Output:DC1.65, 0-100mAx4

Power:3W(MAX)

Charging model: Intelligent Control, led indicator

Temperature range:5℃-30℃

Instruction for charging Ni-MH/Ni-Cd battery:

because Ni-MH/Ni-Cd battery Voltage is 1.2V

maybe the led will not turn off after the battery voltage exceed 1.2V when charging.  If not anxious to use it, do not remove it, the battery will be fully charged within 30 hours, and the LED will off.

If you find the using time of Ni-MH-Ni-Cd battery gets shorter and shorter, it shows the battery has dead. Please replace the new battery. Pls try your best to discharge the battery energy before you charge the Ni-MH-Ni-CD battery.

Notes:

1. Indoor use, do not use it in high-temperature, humidity, high magnetic field environment

2. Do not charging the leakage battery, expired battery, counterfeit and inferior battery.

3. Do not disassembly the charger by yourself, or touch the charger inside with metal objects, in order to avoid electric shock.

4.please buy  1.5V Alkaline rechargeable battery.

5. After charging 1.5V rechargeable alkaline battery for many times, the using time gets more and more shorter, pls replace the new battery.

6.Do not charging the Ni-MH/Ni-Cd battery and Alkaline battery at the same time.
