DAT2045 Thermocouple Transmitter Dip

GENERAL DESCRIPTION

The thermocouple Transmitter DAT2045 is a Din Rail mount Temperature transmitter with DIP Switch programmability.

Suitable for the following thermocouples.

K Type Thermocouples

J Type Thermocouples

S Type Thermocouples

R Type Thermocouples

B Type Thermocouples

T Type Thermocouples

The DAT2045 will linearize the voltage input and provide a 4-20mA output signal.

The DAT2045 is accurate to 0.1% full scale and has less than 0.02%/'f thermal drift.

It is possible to set the minimum and maximum values of the input and output ranges in any point of the scale, keeping the minimum span shown in the table below. Also high burn out indication or low burn out indication is selectable.

The DAT2045 is in compliance with the standard 89/336/CEE on the Electromagnetic Compatibility.

The DAT2045 is housed in a plastic enclosure of 12.5 mm thickness suitable for DIN rail mounting in compliance with EN-50022 and EN-50035 standards.

The DAT2045 has internal cold junction compensation.

The calibration of zero and span values is made by the ZERO and SPAN potentiometers located on the top of device.
