F12-030 F12-040 F12-060 F12-080 F12-090 F12-110 F12-125 F12-152 F12-162 F12-182 F12-250 Pump Parker F12 Motor

F12 is a bent-axis, fixed displacement motor/pump. It can be used in numerous applications in both open and closed loop circuits.
The F12 series is available in sizes 30, 40, 60, 80, 90, 110, 125, 152, 162, 182 and 250 cc.
F12 Features
• Max intermittent pressure up to 480 bar and continuous operating pressure up to 420 bar • The 7 or 9 piston design provides high start-up torque and smooth motor operation
• ISO, Cartridge and SAE versions
F12-030 F12-040 F12-060 F12-080 F12-090 F12-110 F12-125 F12-152 F12-162 F12-182 F12-250 Parker F12 Motor Pump

General Features
• The laminated piston ring offers important advantages such as unbeatable efficiency and thermal shock resistance
• High allowable speeds and operating pressures means high output power
• The unique piston locking, timing gear and bearing set-up as well as the limited number of parts add up to a very robust design with long service life and, above all, proven reliability.
• The 40° angle between shaft and cylinder barrel allows for a very compact, lightweight motor/ pump.
• Small envelop size and a high power-to-weight ratio
• The motor version has highly engineered valve plates for high speed and low noise
• The pump version has highly engineered valve plates for increased self priming speed and low noise, available with left and right hand rotation.
• The F11's and F12's have a simple and straight-forward design with very few moving parts,making them very reliable motors/pumps.
• Our unique timing gear design synchronizes shaft and cylinder barrel, making the F11/F12 very tolerant to high 'G' forces and torsional vibrations.
• Heavy duty roller bearings permit substantial external axial and radial shaft loads.
