Type Outdoor Full Color Led Display

US$ 1000 - 2500 MOQ: 1 Piece

Key Specifications

Brand Name:

SBC

Place of Origin:

China

Model Number:

Shenzhen SBC Photoelectricity Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name SBC

Place of Origin China

Product Features——Stability ,of course SBC!

1.Patented Mask Design: high and quality PC with glass fiber module mask which gives wide angle by attaching to PCB with a flat mounting surface.

2.Kingkong series KG64W, best viewing distance is 64M , pixel pitch 18.75.

3.Unique brightness and chroma correction , can make old screen looks new.

4.High-end display control drive technology,16bit gray scale .level stepping up dust.

5.High refresh frequency , which can make smooth image without wave.

6.Anti-high-temperature: lower temperature for the whole screen, fan or low Pair conditioning can do cooling operation.

Parameters——Stability ,of course SBC!

Type	Outdoor Full Color Display
Best Viewing Distance(m)	64m
Pixel Pitch(mm)	18.75mm
Pixel Density(Dots/sqm)	2844Dots/sqm
Configuration	1R1G1B
Module Size(mm)	300mm x300mm
Unit Box Pixel(Dots)	64Dots x48Dots
Cabinet Size(WxHxT)	1200mm x 900mm x150mm
Cabinet Weight(Kg)	65Kg
Brightness(cd/sqm)	7000cd/sqm
Refresh Frame Frequency	1000Hz
MTBF(H)	10000H
Maximum Power Consumption(W/sqm)	600W/sqm
Average Power Consumption(W/sqm)	400W/sqm
Left/right Viewing Angle(Degree)	140°
Grey Scale	12bit
Display Color	16777216colors
Brightness Adjust	256grade automatic,100grade manual
IP Standard	IP65
Display Module Brightness Uniformity	5%
Pixels Out Of Control Rate(Dots)	1/100000Dots
Life Span(H)	100000H
Operating Voltage	AC220V/50Hz&AC110V/60Hz available
System Working Environment Temperature	—20°C~+60°C
System Working Environment Humidity	10%RH~90%RH
