Outdoor Full Color LED Video Display

Shenzhen SBC Photoelectricity Co.,Ltd

US$ 1000 - 3500 MOQ: 1 Piece

Key Specifications

Brand Name:

SBC

Place of Origin:

China

Model Number:

SBC-O-F-V-Lamp-P16

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name SBC

Place of Origin China

Model Number SBC-O-F-V-Lamp-P16

Outdoor LED Video Display Features:

P16 Full color by filling the whole of imported silica gel, which makes our products in water, antifreeze, superior high-temperature side
After a dustproof and waterproof tested to reach its target IP65
All modules are cross color enhancing, and the edge compression is strong, not deformation, the flatness of display cabinet will be better.
The box with a sliding iron top, bottom chute, and optional locking device to fine-tune the gap and ensure seamless between the box. Plesse do not squeeze the entire screen which ensure good surface smoothness
.Measured by the Shenzhen Institute of Quality Inspection Bureau U.S. core companies of the outdoor full color display for temperature impact test,the results showed that: outdoor full color display can use the power normally under the temperature at -25 °C to +75 °C
Widely used in advertising, sports, industrial enterprises, transportation, stations, terminals, airports, construction, education system and other public places

Product Parameters:

Pixel pitch (mm)	P16
Pixel configuration(R.G.B)	2R1G1B
Pixel density(dots/m²)	3906
Module size(mm) :	256×128
Cabinet size(mm)	1024×768
Cabinet weight(kg/pc)	65
Brightness (nit/sqm.)	6500
Viewing distance (min.-max.) (m)	10m—250m
Viewing angle(H-degree, V-degree)	140°(H), 70°(V)
Gray scale(level)	4096
Refresh frequency(Hz)	9000
IP level(front/rear)	IP65/IP54
Color temperature	6500K±500
MTBF(hours)	10,000 hours
Blind dots rate	≤0.0001
Power consumption(w/m²)	500w(Max); 250w(Average)
Operating environment	—20°C~+60°C
Operating system	WINDOWS(WIN98,WIN2000,WINXP)
Life span	100,000 hours
Control distance	100 m by net line; Optical fiber transmission: 500m- 10km
