Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > Angle Rolling Machine/channel Rolling Machine/Flat Bar Rolling Machine
US$ 500 - 500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Besco
Place of Origin:
China
Model Number:
ABS
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Flat Bar Rolling Machine, U Channel Rolling Machine, Iron Angle Rolling MachineryUS$ 500 - 500MOQ: 1 Set -
Profile Bending Machine/ CNC Profile Bending Machine/Section Bending MachineUS$ 5000 - 5000MOQ: 1 Set
-
Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending MachineUS$ 5000 - 5000MOQ: 1 Set
-
Round Pipe Rolling Machine/square Pipe Rolling Machine/rectangle Pipe Rolling MachineUS$ 500 - 500MOQ: 1 Set
-
Tube Rolling Machine/Pipe Rolling Machine/Ring Rolling MachineUS$ 500 - 500MOQ: 1 Set
Brand Name
Besco
Place of Origin
China
Model Number
ABS
, angle rolling machine/channel rolling machine/flat bar rolling machine
2, Easy operation
3, CE and ISO certification
2, Easy operation
3, CE and ISO certification
The angle rolling machine/channel rolling machine/flat bar rolling machineg machine Features:
1.The main three rollers and curvature adjustment of Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines is drove by hydraulic system, which with stability performance.
2.Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines adopt grating ruler for curvature range adjustment, which with high precision. Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines is allowed to adjust curvature either by two rollers meanwhile, or by single roller according to set, which is easy to operate.
3.Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines use touch panel and PLC electrical control system, with advanced technology and stable performance;
4.With fault auto-detecting system and alarm function, and Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines display error information and solving suggestion on screen;
5.Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines equipe counting function, to record the quantity of processed workpieces
6.All bending data can be saved in PLC of Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines as permanent memory, and can be use at any time.
7.Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines have manual, semi-automatic and automatic work mode. Powerful cooling system allows the Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines could be used in tropic area stably;
8.Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines allow to process varies of metal profile, such as angle iron, flat steel, round pipe and other material of abnormal section profile, through change the groove of bending dies;
9.Besco angle rolling machine/channel rolling machine/flat bar rolling machineg machines is able to bend large size profile, while no need to make super size bending die.
Parameters:
| TPYE(W24Y/W24YPC/W25K-) | 30 | 45 | 75 | 100 | 140 | 180 | 260 | 320 | 400 | 500 |
| profile Max.bend section module(cm*2) | 30 | 45 | 75 | 100 | 140 | 180 | 260 | 320 | 400 | 500 |
| bending speed(m/min) | 5 | 5 | 5 | 5 | 5 | 4 | 4 | 4 | 4 | 4 |
| profile yield limit (Mpa) | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 |
| Max hydraulic pressure(kw) | 8 | 12 | 14 | 16 | 16 | 16 | 18 | 20 | 25 | 25 |
| oil pump pressure(kw) | 12 | 16 | 16 | 21 | 21 | 21 | 25 | 31.5 | 31.5 | 31.5 |
| measure ment(L*W*H)(M) | 1.6*1.2*11 | 1.8*1.5*1.2 | 2.1*1.8*1.6 | 2.2*1.9*1.6 | 2.5*2.2*1.6 | 3.1*2.3*1.8 | 3.6*2.6*1.8 | 4.0*3.2*2 | 4.5*3.5*2.2 | 5.5*4.0*2.5 |
| weight(kg) | 3400 | 5000 | 7000 | 9000 | 11000 | 16000 | 23000 | 30000 | 36000 | 4 |
