Home > Manufacturing & Processing Machinery > Cutting & Fold-bend Machine > Bending Machine > Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending Machine
US$ 5000 - 5000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Besco
Place of Origin:
China
Model Number:
ABS
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Round Pipe Rolling Machine/square Pipe Rolling Machine/rectangle Pipe Rolling MachineUS$ 500 - 500MOQ: 1 Set -
Tube Rolling Machine/Pipe Rolling Machine/Ring Rolling MachineUS$ 500 - 500MOQ: 1 Set
-
Steel Pipe Bending Machine/aluminum Pipe Bending Machine/stainless Steel Pipe Bending MachineUS$ 5000 - 5000MOQ: 1 Set
-
Steel Tube Rolling Machine/aluminum Tube Rolling Machine/stainless Steel Tube Rolling MachineUS$ 500 - 500MOQ: 1 Set
-
Angle Rolling Machine/channel Rolling Machine/Flat Bar Rolling MachineUS$ 500 - 500MOQ: 1 Set
Brand Name
Besco
Place of Origin
China
Model Number
ABS
The Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machine Features:
1.The main three rollers and curvature adjustment of Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines is drove by hydraulic system, which with stability performance.
2.Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines adopt grating ruler for curvature range adjustment, which with high precision. Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines is allowed to adjust curvature either by two rollers meanwhile, or by single roller according to set, which is easy to operate.
3.Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines use touch panel and PLC electrical control system, with advanced technology and stable performance;
4.With fault auto-detecting system and alarm function, and Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines display error information and solving suggestion on screen;
5.Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines equipe counting function, to record the quantity of processed workpieces
6.All bending data can be saved in PLC of Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines as permanent memory, and can be use at any time.
7.Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines have manual, semi-automatic and automatic work mode. Powerful cooling system allows the Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines could be used in tropic area stably;
8.Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines allow to process varies of metal profile, such as angle iron, flat steel, round pipe and other material of abnormal section profile, through change the groove of bending dies;
9.Besco Tube Bending Machine/Pipe Bending Machine/Iron Angle Bending machines is able to bend large size profile, while no need to make super size bending die.
| TPYE (W24Y/W24YPC/W25K-) | 30 | 45 | 75 | 100 | 140 | 180 | 260 | 320 | 400 | 500 |
| profile Max.bend section module(cm*2) | 30 | 45 | 75 | 100 | 140 | 180 | 260 | 320 | 400 | 500 |
| bending speed(m/min) | 5 | 5 | 5 | 5 | 5 | 4 | 4 | 4 | 4 | 4 |
| profile yield limit (Mpa) | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 | 250 |
| Max hydraulic pressure(kw) | 8 | 12 | 14 | 16 | 16 | 16 | 18 | 20 | 25 | 25 |
| oil pump pressure(kw) | 12 | 16 | 16 | 21 | 21 | 21 | 25 | 31.5 | 31.5 | 31.5 |
| measure ment(L*W*H)(M) | 1.6*1.2*11 | 1.8*1.5*1.2 | 2.1*1.8*1.6 | 2.2*1.9*1.6 | 2.5*2.2*1.6 | 3.1*2.3*1.8 | 3.6*2.6*1.8 | 4.0*3.2*2 | 4.5*3.5*2.2 | 5.5*4.0*2.5 |
| weight(kg) | 3400 | 5000 | 7000 | 9000 | 11000 | 16000 | 23000 |
