BER Tester (BER-1530)

BER Tester (BER-1530) photo-1
Negotiable MOQ: 1 Case (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
DADI
Place of Origin:
China
Model Number:
BER-1530
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Brand Name DADI
Place of Origin China
Model Number BER-1530

Model: BER-1530 Data Transmission Analyzer



Overview:

BER-1530 Data Transmission Analyzer is the latest compact handheld tester developed by DADI. It can be for E1/2M on-line monitoring as well as BER test from 50b/s to 2048kb/s, which is the necessary tool for network equipment installation, troubleshooting and maintenance.

The BER-1530 is configured with large touch screen TFT color LCD, and built-in rechargeable Li-ion battery for more than 8 hours’ working without external power supply. BER-1530 also supports large capacity records storage and on-line upgrading.



Functions:

G.703 E1 In-service / Out of Service Test

o    Various alarm and error insert

o    Balance interface (75 Ohm) / unbalanced interface (120 Ohm) for E1

o    ITU-T G.821/G.826/M2100 BER analysis

o    Pattern slips analysis

o    Clock slips analysis

o    Clock frequency offset test

o    NX64K test

o    Frame setting / analysis

o    PCM / time slot detection

o    Time slot data display

o    Histogram display

o    Voice monitoring

o    Auto test

o    Loopback delay test

o    Switching time test

V Series Interface Test (optional)

o    V.24/RS232, V.35, V.36/RS449, EIA-530/530A, X.21 interface BER tests

o    Various working mode settings

o    Compliance with ITU standards



Features:

o    Color touch screen TFT LCD.

o    Various BER insert and detection like bit, Code, FAS, CRC etc.

o    Large capacity Li-ion battery guarantees more than 8 hours’ working without external power supply.

o    Large capacity digital storage for more than 5000 records.

o    Test records can be transferred to PC by USB.

o    Powerful PC software E1/2M data management system for detailed and completed management and analysis of test data.
