Stationary Asphalt Mixing Plant ZS 105.
Technical Parameters
1. Production capacity (standard condition): 105t / h;
2. Coal-fired capacity (standard condition): 10kg / t;
3. Operation: manual, semi-automatic, automatic;
4. Overall Dimensions (approx.): 40m × 29m × 14m;
5. The total installed capacity: 288kW;
Main Components List :
1. Cold aggregate supply system-----hoppers , belt feeder , aggregate belt conveyer.
2. Drying Drum
3. Burning system-----coal pulverizer, burner, fuel oil igniting system
4. Hot aggregate elevator
5. Asphalt Mixer-----Twin Shaft Mixer
6. weighing system
7. Dust catcher system -----Cyclone dust catcher and water dust catcher
8. Powder supply system----- spiral conveyer
9. Pneumatic control system----- Air compressor, cylinder,electromagnetic valve
10. Asphalt supply-----Coal-fired heating asphalt tank
11. Control System-----PLC & Auto Control
Quality Control (QC):
Third Control
ISO9001:2000 Certificate
European CE Certificate
Enviroment Protection Design
Commercial Term :
Delivery Time : 30~40 Working Days
Payment Term : T/T or L/C
Transportation : by sea or railway in container.
After Sale Service :
1. Turn-Key Solutions
2. Erection & Commissioning Service
3. Operation Training Service
4. Spare Parts Supply ( all working life )
Warranty Period : 12~15 months since delivery the machine .
More information can be get by contact with Henan Sinosun
