Detailed Product Description
1.long lifespan
2.high-precision
3.higher capacity
4.easy operation.
U channel profile roll forming machine, roll forming machine, U purlin roll forming machine, U steel profile forming machine
U channel profile roll forming machine is for roll forming different profile as designed
Technical specifications:
1. Material Width: 500mm max.
2. Material Thickness: 2.0mm-3.0 mm.
3. Forming speed: 12m-15m/min.
4. Forming stations: according your profiles
5. Material of the main shaft and rollers: forged Cr12, queching HRC58-62°
6. Material of hydraulic cutter: Cr12 Mov
7. Power of main motor : 11kw.
8. Power of hydraulic station: 7.5kw.
9. Electric control system: PLC.
10. Driving system: chain driven by motor reducer
11. Dimensions: about 10500mmx1500mmx1400mm.
The equipment include:
1. Un-coiler, 1 set
2. Main Roll forming machine, 1 set
3. Hydraulic cutting, 1 set
4. Hydraulic station, 1 set
5. Electric controlling system, 1 set
6. Product rack (un-powered), 1 set
7. Instruction Book, 1 piece
